RVS Systems RVS-770613-213-01 620 TVL Backup Camera, 7" Display, Trailer Tow Quick Connect Kit
- Trailer Tow Quick Connect Kit - for Trucks and Trailers
- 7" LED Digital Panel Color Monitor
- Completely Waterproof Backup Camera - IP69K
- 130° Viewing Angle with 18 Infra-red Night Vision Lights
- Built-In Mic on Camera and Speakers on Monitor for Audio
RVS Systems RVS-770613-213-01 Backup Camera Features
The RVS-770613-213-01 from RVS Systems is a backup camera system is perfect for the fifth wheel application. The system is complete with a crystal clear 7" LED DIGITAL Panel COLOR monitor with mirror image capability and distance grid lines, a 3 channel power harness with automatic system switch, one 130° CCD camera with 50-foot infra-red night vision and all the wires, connectors and mounts you will need. The 5th wheel rearview camera system is completely weatherproof with an IP69K rating. The quick connect/disconnect cable is 66' to the camera, 26' to monitor with a 12' pigtail. The system is strong and reliable with a camera that boasts a 20G vibration and 100G impact rating (highest in the industry).
The RVS-6137-NM has a crystal clear 7" LED Digital Panel display and is equipped with adjustable distance grid lines, mirror image capability, a 3 port power harness with automatic system switch, and a built-in speaker.
The RVS-770 is a commercial grade backup camera is the clearest and greatest camera available on the market today. It boasts a 410,000 pixel 2.5 mm lens with 18 infra-red illuminators which enable you to see in total darkness and a built-in microphone which enables you to hear what is behind you. The backup camera is completely weatherproof with an IP69K rating, strong and reliable, shock resistant with a 20G vibration and 100G impact rating (highest in the industry).
The RVS-213-613 from RVS Systems is one camera Trailer Tow Quick Connect/Disconnect Kit for the RVS-770613-213 and RVS-770614-213 systems. These cables allow one to wire his truck and trailer separately and connect/disconnect with just one pigtail cable.
Features
- Trailer Tow Quick Connect Kit: Connects truck and trailer quickly and easily, enhancing convenience during towing.
- 7" LED Digital Panel Color Monitor: Provides clear visuals, ensuring you can see obstacles while backing up with ease.
- Completely Waterproof Backup Camera: With an IP69K rating, it withstands harsh weather conditions for reliable performance.
- 130° Viewing Angle: Offers a wide perspective to capture more of your surroundings, enhancing safety.
- Built-In Mic on Camera and Speakers on Monitor: Enables audio feedback from behind the vehicle, improving situational awareness.
RVS Systems RVS-770613-213-01 Detailed Specifications
| Display Size | 7" LED Digital Panel |
| Camera Resolution | 620 TVL |
| Viewing Angle | 130° |
| Camera Weatherproof Rating | IP69K |
| Night Vision | 18 Infra-red Lights (50-foot range) |
| Microphone | Built-In on Camera |
| Shock Resistance | 20G Vibration / 100G Impact |
| Quick Connect Cable Length | 66' to Camera, 26' to Monitor, 12' Pigtail |
SKU  | RVS-770613-213-01 |
|---|---|
| Features | Auto Gain Control, Weather Resistant |
| Manufacturer | RVS Systems |
Camera Signal  | Analog |
| Resolution | 620 TVL |
| Sensor Option | 1/3" CCD |
| Lens Type | Fixed |
| Lens Size | 2.5mm |
| Infrared Distance | 0~60 Feet |
| Durability | Weather Resistant |
| Gamma Correction | r=0.45 to 1.0 |
| Image Device | 1/3" Sharp® Color CCD |
| IR Distance | 15.24m/50ft |
| Minimum Scene Illumination | 0 Lux (IR On) |
| Operating Temperature | -40°C ~ +70°C / RH 95% Max |
| Power Consumption | 5W |
| S/N Ratio | More than 48dB |
| Video Output | 1Vp-p 75 Ω |
| Weatherproof | IP69K |
| Synchronization | Internal Synchronization |
| Angle of View | 130° |
| Auto Gain Control | Yes |
