RVS Systems RVS-355W-SC-02 540 TVL Wireless Backup Camera, Left Side Camera, 7" Wireless Display, Suction Cup Mount
SKU
RVS-355W-SC-02
Model No
RVS-355W-SC-02
$524.76
Product Highlights
- 7" LED Digital Monitor with Suction Cup Mount
- Waterproof Backup Camera with Infra-Red Night Vision
- Two Wired inputs - Connect Up To Two Side Cameras
- Guaranteed transmission of 100ft Even At Highway Speeds!
- Instant Pair - Pair System Without Leaving Your Cab
Speak to an expert
The RVS-355W-SC-02 from RVS Systems is perfect for truck and trailer applications. Two wired side cameras install easily to your truck and the backup camera is wireless to allow easy installation on your trailer. Part of our new SimpleSight series, the system is equipped with instant pair, allowing you to easily swap between trucks and trailers. Simply hit pair from the menu and turn on power for the trailer and the system will pair automatically. This system features optional adjustable distance grid lines. cameras comes with 7" Wireless Display, Suction Cup Mount.
RVS Systems RVS-355W-SC-02 Camera Features
- 7" LED Digital Monitor with Suction Cup Mount: Provides a clear view of your surroundings during backup and trailer maneuvers.
- Waterproof Backup Camera with Infra-Red Night Vision: Ensures reliable visibility in all weather conditions and low-light environments.
- Two Wired Inputs: Connects Up To Two Side Cameras - Expands your visibility range with additional cameras for enhanced safety.
- Guaranteed Transmission of 100ft Even At Highway Speeds: Offers stable and clear video feed even at high speeds, ensuring a worry-free driving experience.
- Instant Pair: Pair System Without Leaving Your Cab - Enhances convenience by allowing quick switching between different trailer setups without extra effort.
RVS Systems RVS-355W-SC-02 Detailed Specifications
| Product Type | Wireless Backup Camera System |
| Monitor Size | 7 inches |
| Camera Type | Waterproof, Infra-Red Night Vision |
| Number of Cameras Included | 1 Backup Camera, 2 Wired Side Cameras (optional) |
| Transmission Range | Up to 100ft |
| Mounting Type | Suction Cup Mount |
SKU  | RVS-355W-SC-02 |
|---|---|
| Features | Auto Gain Control, Weather Resistant |
| Manufacturer | RVS Systems |
Camera Signal  | Analog |
| Resolution | 540 TVL |
| Sensor Option | 1/4" CCD |
| Lens Type | Fixed |
| Lens Size | 2.1mm |
| Infrared Distance | 0~60 Feet |
| Durability | Weather Resistant |
| Gamma Correction | R=0.45 TO 1.0 |
| Image Device | 1/4" SHARP COLOR CCD |
| IR Distance | Wireless Backup Camera: 15.24m / 50ft, Side Camera: 9.14m / 30ft |
| Minimum Scene Illumination | 0 Lux (IR ON) |
| Operating Humidity | RH 95% |
| Operating Temperature | Wireless Backup Camera:-30°C~+80°C, Side Camera: -40°C~+80°C |
| S/N Ratio | More than 48dB |
| Signal System | NTSC / PAL |
| Video Output | 1Vp.p 75 ohm |
| Weatherproof | IP69K |
| Synchronization | INTERNAL SYNCHRONIZATION |
| Angle of View | Wireless Backup Camera: 130°, Side Camera: 120° |
| IR LEDs | 9 LED |
| Auto Gain Control | Yes |
