RVS Systems RVS-355W-SC-01 540 TVL Wireless Backup Camera, Right Side Camera, 7" Wireless Display, Suction Cup Mount
SKU
RVS-355W-SC-01
Model No
RVS-355W-SC-01
$524.76
Product Highlights
- 7" LED Digital Monitor with Suction Cup Mount
- Waterproof Backup Camera with Infra-Red Night Vision
- Two Wired inputs - Connect Up To Two Side Cameras
- Guaranteed transmission of 100ft Even At Highway Speeds!
- Instant Pair - Pair System Without Leaving Your Cab
Speak to an expert
RVS Systems RVS-355W-SC-01 Camera Features
The RVS-355W-SC-01 from RVS Systems is perfect for truck and trailer applications. Two wired side cameras install easily to your truck and the backup camera is wireless to allow easy installation on your trailer. Part of our new SimpleSight series, the system is equipped with instant pair, allowing you to easily swap between trucks and trailers. Simply hit pair from the menu and turn on power for the trailer and the system will pair automatically. This system features optional adjustable distance grid lines. cameras comes with 7" Wireless Display, Suction Cup Mount.
Features
- Display: 7" LED Digital Monitor with Suction Cup Mount - Offers clear visibility and easy installation without drilling.
- Camera Type: Waterproof Backup Camera with Infra-Red Night Vision - Ensures safety and reliability in all weather conditions and during night-time use.
- Input Options: Two Wired inputs - Connect Up To Two Side Cameras - Customize your setup for enhanced visibility around your vehicle.
- Transmission Range: Guaranteed transmission of 100ft Even At Highway Speeds! - Reliable performance for larger vehicles, enhancing safety during travel.
- Pairing Feature: Instant Pair - Pair System Without Leaving Your Cab - Allows for rapid transitions between different vehicles without hassle.
RVS Systems RVS-355W-SC-01 Detailed Specifications
| Feature | Details |
| Model | RVS-355W-SC-01 |
| Camera Type | Wireless Backup Camera |
| Monitor Size | 7 inches |
| Camera Resolution | 540 TVL |
| Mount Type | Suction Cup |
| Nigh Vision | Infra-Red |
| Waterproof Rating | Yes |
| Transmission Distance | 100ft |
| Wired Inputs | 2 |
| Installation Type | Easy Installation |
SKU  | RVS-355W-SC-01 |
|---|---|
| Features | Auto Gain Control, Weather Resistant |
| Manufacturer | RVS Systems |
Camera Signal  | Analog |
| Resolution | 540 TVL |
| Sensor Option | 1/4" CCD |
| Lens Type | Fixed |
| Lens Size | 2.1mm |
| Infrared Distance | 0~60 Feet |
| Durability | Weather Resistant |
| Gamma Correction | R=0.45 TO 1.0 |
| Image Device | 1/4" SHARP COLOR CCD |
| IR Distance | Wireless Backup Camera: 15.24m / 50ft, Side Camera: 9.14m / 30ft |
| Minimum Scene Illumination | 0 Lux (IR ON) |
| Operating Humidity | RH 95% |
| Operating Temperature | Wireless Backup Camera:-30°C~+80°C, Side Camera: -40°C~+80°C |
| S/N Ratio | More than 48dB |
| Signal System | NTSC / PAL |
| Video Output | 1Vp.p 75 ohm |
| Weatherproof | IP69K |
| Synchronization | INTERNAL SYNCHRONIZATION |
| Angle of View | Wireless Backup Camera: 130°, Side Camera: 120° |
| IR LEDs | 9 LED |
| Auto Gain Control | Yes |
