Hanwha Vision PND-A9081RVX 8 Megapixel Network Outdoor Dome Camera with 4.5-10mm Lens
SKU
PND-A9081RVX
Model No
PND-A9081RVX
$1,001.72
Product Highlights
- Camera module for easy upgrade of existing indoor modular cameras.
- 4K / 8 megapixel (3840 x 2160) resolution
- [email protected] (Color), 0 Lux (B/W IR LED On)
- 30fps@all resolutions (H.265/H.264)
- Video Analytics based on AI
Speak to an expert
8 Megapixel Network Outdoor Dome Camera with 4.5-10mm Lens
- The Hanwha Vision PND-A9081RVX is a cutting-edge 8 Megapixel Network Outdoor Dome Camera designed for high-performance security surveillance. With a stunning 4K resolution and advanced AI capabilities, this camera ensures exceptional image quality and smart analytics for effective monitoring. The motorized varifocal lens offers flexibility in focal length, while features like face mask detection and social distancing analytics make it ideal for various environments, ensuring safety and compliance.
Camera Functions
Audio
Auto Gain Control
Auto White Balance
BLC
Day/Night Vision
3D DNR
Mirror
Motion Detection
ONVIF
Privacy Masking
Vandal Resistant
Weather Resistant
WDR
Camera Features
| Camera module for easy upgrade of existing indoor modular cameras. | Day & Night (ICR), WDR (120dB), P-Iris |
| 4K / 8 megapixel (3840 x 2160) resolution | Digital image stabilization with built-in Gyro sensor |
| [email protected] (Color), 0 Lux (B/W IR LED On) | Face mask detection, loitering, directional detection, audio detection, sound classification, tampering, shock detection |
| 30fps@all resolutions (H.265/H.264) | Motion detection, PTZ Handover, audio event playback, digital auto tracking |
| Video Analytics based on AI | 30m (98ft) IR Illumination |
| Classified object type: Person/Face/Vehicle/License plate | Dual SD/SDHC/SDXC memory slots (Maximum total capacity 512GB) |
| Attributes: Person (Gender, Color and Bag), Face (Age, Gender, Mask and Glasses), Vehicle (Type: car/bus/truck/motorcycle/bicycle and Color) | Hallway view, WiseStream III support |
| Support Bestshot per object | LDC support (Lens Distortion Correction) |
| Analytics events based on AI engine - Object detection, Virtual line* (Crossing/Direction), Virtual area* (Loitering/Intrusion/Enter/Exit), Face mask detection, Digital auto tracking, Social distancing detection Analytics events - Defocus detection, Motion detection, Tampering, Audio detection, Sound classification, Shock detection, Virtual area (Appear/Disappear) *Some of the video analytics only works with people and vehicle detection | PoE+ / 12vDC, Bi-directional audio support |
| 4.5~10mm (2.2x) motorized varifocal lens | IP / IK rating based on camera housing used |
| H.265, H.264, MJPEG codec supported, multiple streaming |
Additional Hanwha Vision Products
SKU  | PND-A9081RVX |
|---|---|
| Features | Audio, Auto Gain Control, Automatic White Balance, Back Light Compensation, Day/Night, Digital Noise Reduction, Mirror, Motion Detection Tracking, ONVIF, Privacy Masking, Vandal Resistant, Weather Resistant, Wide Dynamic Range |
| Manufacturer | Hanwha Vision |
Camera Signal  | Network IP |
| Connection Type | Wired |
| Infrared Distance | 61~100 Feet |
| Resolution | 8 Megapixel |
| Lens Type | Fixed |
| Lens Size | 4.5-10mm |
| Mount Type | Ceiling, Wall |
| Compression Method | H.264, M-JPEG, H.265 |
| Durability | Vandal Resistant, Weather Resistant |
| Voltage | 12vDC, PoE |
| Automatic Gain Control (AGC) | Low / Middle / High |
| Dimensions (W x H) | ø137.7x104.9mm(ø5.42x4.13") |
| Electronic Shutter | Speed Minimum / Maximum / Anti flicker(1/5~1/12,000sec) Prefer shutter control(Based on AI en |
| Image Device | 1/1.8" CMOS |
| Minimum Scene Illumination | Color: 0.05Lux(F1.6, 1/30sec), BW: 0.005Lux(F1.6, 1/30sec), 0Lux(IR LED on) |
| Operating Humidity | 0~90% RH |
| Operating Temperature | -40°C~+55°C(-40°F~+131°F) |
| Power Consumption | PoE+: Max 20.00W, typical 16.00W, 12VDC: Max 17.70W, typical 14.00W |
| Privacy Zone | sking 6ea, Rectangle zones - Color: Gray/Black |
| Protocols | IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP, SRTP (TCP, UDP Unicast) |
| Weatherproof | IP66 |
| Digital Noise Reduction | WiseNRâ…¡(Based on AI engine), |
| Angle of View | H: 102°(Wide)~45°(Tele), V: 54°(Wide)~25°(Tele), D: 121°(Wide)~52°(Tele) |
| Rotation Angle | Flip, Mirror, Hallway view(9 |
| Motion Detection Tracking | 8ea, polygonal |
| Back Light Compensation | BLC, WDR, SSDR |
| Automatic White Balance | ATW / AWC / Manual / Indoor / Outdoor |
| IR Distance | 30m/98.42ft |
| Audio | Yes |
| Auto Gain Control | Yes |
| Day/Night | Yes |
| Digital Noise Reduction | Yes |
| Automatic White Balance | Yes |
| Back Light Compensation | Yes |
| Motion Detection Tracking | Yes |
| Privacy Masking | Yes |
| Wide Dynamic Range | Yes |
| Mirror | Yes |
| ONVIF | Yes |
