Pelco NVX220P00A 2 Megapixel Network Outdoor Bullet Camera with 30X
SKU
NVX220P00A
Model No
NVX220P00A
$2,638.51
Product Highlights
- Exceptional corrosion resistance
- Video recordings with incredibly bright day and night colours
- Quick connectors and modular integrated support
- Version available with polycarbonate window
Speak to an expert
2 Megapixel Network Outdoor Bullet Camera
- The NVX camera is entirely made of AISI 316L stainless steel and stands out for its exceptional resistance to corrosion. NVX was designed to guarantee efficient videosurveillance in offshore/onshore marine environments, but also in applications for the rail and transport sectors. Thanks to its mechanical characteristics, compact design, and lightweight, its use is also indicated in industrial environments, in particular in foodstuff industry applications, with the possibility of mounting the polycarbonate window. The high anti-corrosion properties of its AISI316L stainless steel structure combined with the vast temperature range and the IP66/IP67/IP68 degrees of protection guarantee complete protection against bad weather and temporary immersion in water. In addition, the IP69 certification allows camera cleaning with high-pressure water jets at high temperatures.
- Installation of NVX even in tight spaces is facilitated by the quick connectors and the practical, modular support supplied as standard for assembly on walls, ceilings or railings. NVX versions are available with an integrated wiper or with a polycarbonate window. This camera is certified by Lloyd's Register Type Approval System Test Specification Number 1. It can therefore be used in marine applications for environmental categories that include boats, ships, open decks, enclosed spaces, technical premises subject to heat generated by other equipment or as a visual support for mooring manoeuvres (ENV1, ENV2, ENV3 and ENV5).
Camera Functions
Auto Gain Control
Auto White Balance
BLC
Day/Night Vision
3D DNR
Digital Zoom
Flickerless
Motion Detection
Onvif
Privacy Masking
Weather Resistant
WDR
Camera Features
| Exceptional corrosion resistance | Quick connectors and modular integrated support |
| Video recordings with incredibly bright day and night colours | Version available with polycarbonate window |
Durable PTZ Cameras for Reliable Performance
PTZ (pan-tilt-zoom) cameras make it possible to monitor large areas with a single camera, offering both wide and close-up views for the details required. Our PTZ IP cameras are designed for both indoor and outdoor applications to work in all lighting and weather conditions.
Wide area coverage- Never miss a moment with 360-degree views and wide tilt range.
Integrated IR illumination- See up to 200m in the dark with integrated IR illumination.
Low latency - Track objects easily with low latency, smooth pan, tilt and zoom controls.
Additional Pelco Products
SKU  | NVX220P00A |
|---|---|
| Features | Auto Gain Control, Automatic White Balance, Back Light Compensation, Day/Night, Digital Noise Reduction, Digital Zoom, Flickerless, Motion Detection Tracking, ONVIF, Privacy Masking, Weather Resistant, Wide Dynamic Range |
| Manufacturer | Pelco |
Camera Signal  | Network IP |
| Connection Type | Wired |
| Infrared Distance | Non Infrared |
| Resolution | 2 Megapixel |
| Lens Type | Motorized Zoom |
| Lens Size | 30X |
| Mount Type | Wall |
| Compression Method | H.264, MPEG-4, M-JPEG |
| Durability | Weather Resistant |
| Voltage | PoE+, 24vDC, 24vAC |
| Automatic Gain Control (AGC) | 0dB up to 50.0dB (Auto, Manual) |
| Dimensions (W x H) | 36x35x23cm (14x14x9in) |
| Electronic Shutter | 1/1s up to 1/10000s (Auto, Manual) |
| Image Device | 1/2.8" Exmor™ R CMOS sensor |
| Image Pixels-Effective | Approx. 2.13 Megapixels |
| Minimum Scene Illumination | Colour: 0.0013lx (50 IRE, High sensitivity on), B/W: 0.0008lx (30 IRE, High sensitivity on) |
| Operating Humidity | 5% up to 95% |
| Operating Temperature | -34°C (-29.2°F) to +74°C (165.2°F |
| Power Consumption | 21W |
| Privacy Zone | Privacy zones masking (maximum 8 settable masks) |
| Weatherproof | IP66/IP67/IP68/IP69 |
| Digital Noise Reduction | 2D, 3D |
| Angle of View | Horizontal Viewing Angle: from 63.7° (wide end) up to 2.3° (tele end), Vertical Viewing Angle: from 38.5° (wide end) up to 1.3° (tele end) |
| Auto Gain Control | Yes |
| Day/Night | Yes |
| Automatic White Balance | Yes |
| Back Light Compensation | Yes |
| Flickerless | Yes |
| Motion Detection Tracking | Yes |
| Privacy Masking | Yes |
| Wide Dynamic Range | Yes |
| ONVIF | Yes |
| Digital Zoom | Yes |
