Pelco NTX2HRR00A 720 X 480 Network Outdoor PTZ Camera with 9mm Lens

SKU
NTX2HRR00A
Model No
NTX2HRR00A
$23,000.00
Volume Discounts Volume
Discounts
Free System Design Free System
Design
Lifetime Tech Support Lifetime
Tech Support
Free Shipping Over $450* Free Shipping
Over $450*
Product Highlights
  • Made of electropolished AISI 316L stainless steel
  • Radiometric analysis
  • Complies with ONVIF, Profile Q, Profile S and Profile T
  • Digitally signed firmware
  • Complies with ONVIF Security Service specifications

The Pelco NTX2HRR00A 720 X 480 Network Outdoor PTZ Camera is designed for robust and reliable surveillance in challenging environments. Constructed from electropolished AISI316L stainless steel, this camera delivers superior durability, ideal for critical use in marine and industrial sectors. With advanced thermal imaging capabilities and compliance with major ONVIF protocols, it not only ensures precision monitoring and alarm functions but also facilitates seamless integration into existing systems.

Pelco NTX2HRR00A Camera Features

  • Stainless Steel Construction: Made of electropolished AISI 316L stainless steel, providing exceptional durability and corrosion resistance.
  • Radiometric Analysis: Offers advanced temperature detection to monitor critical processes, enhancing safety and preventive measures.
  • ONVIF Compliance: Fully compliant with ONVIF Profile Q, Profile S, and Profile T, ensuring easy integration with various Video Management Systems (VMS).
  • Digitally Signed Firmware: Ensures software authenticity and security, enhancing operational reliability.
  • ONVIF Security Service Compliance: Adheres to high security standards for secure data transmission.
  • High-Quality Image Device: Utilizes an uncooled VOx microbolometer for clear thermal imaging.
  • Remote Management Capabilities: Features 1 input for remote reset and 1 relay output for efficient monitoring and control.
  • Flexible Power Supply: Operates on 24Vdc/24Vac and PoE+, providing versatility in installation.
  • Wide Operating Temperature Range: Functions from -40°C (-40°F) to +65°C (149°F), suitable for extreme weather conditions.
  • Quick Connectors: Facilitates easy installation and maintenance, saving time and resources.
  • Modular Support: Built-in support for wall, ceiling, or parapet installation, enhancing mounting options.

Pelco NTX2HRR00A Detailed Specifications

FeatureDetail
ModelPelco NTX2HRR00A
Image Resolution720 x 480
Lens9mm
MaterialElectropolished AISI316L stainless steel
Thermal Imaging TechnologyUncooled VOx microbolometer
Input/Output1 input for remote reset, 1 relay output
Power Supply24Vdc/24Vac, PoE+
Operational Temperature Range-40°C to +65°C
WeightLightweight design for easy installation
Regulatory ComplianceLloyd’s Register Marine Type Approval, railway application standards
SKU  NTX2HRR00A
Features  Auto Gain Control, Day/Night, Flickerless, Motion Detection Tracking, ONVIF, Privacy Masking
Manufacturer  Pelco
NDAACompliant
Camera Signal     Network IP
Connection Type  Wired
Infrared Distance    Non Infrared
Resolution    720 X 480
Lens Type    Fixed
Lens Size    9mm
Mount Type  Bracket Required
Compression Method    H.264, MPEG-4, M-JPEG, JPEG
Durability    Weather Resistant
Voltage  24vAC
Dimensions (W x H)  6x35x23cm (14x14x9in) -
Electronic Shutter    Video stop < 1sec
Operating Humidity    5% up to 95%
Operating Temperature    -40°C (-40°F) up to +65°C (149°F)
Power Consumption  21W
Weatherproof    IP66|IP67|IP68|IP69
Auto Gain Control    Yes
Motion Detection Tracking    Yes
Privacy Masking    Yes
Wide Dynamic Range    Yes
ONVIF  Yes
