Luminys N5D-8LA2 8 Megapixel Network IP LumiLuxSmart Dome Camera with 2.8mm Lens

SKU
N5D-8LA2
Model No
N5D-8LA2
$305.54
Volume Discounts Volume
Discounts
Free System Design Free System
Design
Lifetime Tech Support Lifetime
Tech Support
Free Shipping Over $450* Free Shipping
Over $450*
Product Highlights
  • 8MP Dome Housing
  • 2.8 mm Lens
  • LumiLuxSmart — IR and White-Light LEDs
  • Video Content Analytics+: Line Crossing, Intrusion, Loitering Detection, Parking Detection
  • LumiAnalytics: Face Detection, People Counting, Heat Map, Queue Management, Smart Object Detection

Luminys is lighting the way for flexible low-light solutions with the LumiLuxSmart Mainstream Series, the industry’s most extensive dual-functioning camera lineup.

LumiLuxSmart cameras allow users to switch between three low-light functionalities: covert IR-only mode, nighttime white-light LED lighting, and motion-activated IR and LED dual-illumination. The brightness and intensity of the white-light LEDs can be remotely adjusted, preventing unnecessary light pollution.

The LumiLuxSmart series provide unparalleled customization and flexibility to meet the needs of today’s evolving security market.

Luminys LumiLuxSmart Features

  • 8MP Dome Housing: Offers high-resolution images for enhanced surveillance quality.
  • 2.8 mm Lens: Provides a wider field of view, ensuring comprehensive area coverage.
  • LumiLuxSmart — IR and White-Light LEDs: Allows users to choose between invisibility in darkness or visible illumination for safety and security.
  • Video Content Analytics+: Includes advanced features like Line Crossing, Intrusion, Loitering Detection, and Parking Detection, maximizing security efficiency.
  • LumiAnalytics: Equipped with Face Detection, People Counting, Heat Map, Queue Management, and Smart Object Detection for intelligent video analytics.
  • LumiSearch+: Streamlines search capabilities in recorded video footage for faster incident review.
  • iMD: Integrated motion detection technology enhances security alertness.
  • LumiPower: Ensures optimal power management for long-lasting performance.
  • LumiPolarPro and LumiDesertPro: Tailored for unique environmental conditions, ensuring effective performance across diverse settings.

Luminys LumiLuxSmart Detailed Specifications

Camera Resolution8MP
Lens Type2.8 mm
Low-Light ModesIR-only, White-Light, Dual-Illumination
Video AnalyticsLine Crossing, Intrusion, Loitering, Parking Detection
Smart FeaturesFace Detection, People Counting, Heat Map, Queue Management, Smart Object Detection
Motion Detection TechnologyiMD
Power ManagementLumiPower
Environmental AdaptationLumiPolarPro, LumiDesertPro
SKU  N5D-8LA2
Features  Audio, Auto Gain Control, Day/Night, Digital Noise Reduction, Mirror, Motion Detection Tracking, ONVIF, Privacy Masking, Vandal Resistant, Weather Resistant, Wide Dynamic Range, Facial Recognition
Manufacturer  Luminys
NDAACompliant
Camera Signal     Network IP
Connection Type  Wired
Infrared Distance    61~100 Feet
Resolution    8 Megapixel
Lens Type    Fixed
Lens Size    2.8mm
Mount Type  Ceiling, Wall
Compression Method    H.264, M-JPEG, H.265, H.264+, H.265+
Durability    Vandal Resistant, Weather Resistant
Voltage  12vDC, PoE
Dimensions (W x H)  126.0 mm × 100.0 mm (5.0 in. × 4.0 in.)
Electronic Shutter    Automatic, Manual 1/3 s to 1/100,000 s
Image Device    1/1.8-in. 8MP Progressive CMOS
IR LEDs  Two (2)
Minimum Scene Illumination  Color: 0.0008 Lux at F1.4 , Black/White: 0.0005 Lux at F1.4 0 Lux With IR Light On
Operating Humidity    < 95% RH (Non-Condensing)
Operating Temperature    -40 to 60 °C (-40 to 140 °F)
Power Consumption  12 VDC: Maximum: 8.1 W, Normal: 4.1W , PoE: Maximum: 9.8 W, Normal: 5.2 W
Protocols  IPv4, IPv6, HTTP, TCP, RTSP, RTMP, SNMP, FTP, NAS, DHCP, DDNS, QoS, UPnP, NTP, Multicast, NFS, PPPoE
S/N Ratio  > 50 dB
Weatherproof    IP67, IK10
Digital Noise Reduction    3D NR
Mirror    Supported
Angle of View    Horizontal: 110° , Vertical: 57° , Diagonal: 134°
Motion Detection Tracking    Supported with Alarms for Vehicles and Humans
IR Distance  30m/98.4ft
AudioYes
Auto Gain Control    Yes
Day/Night    Yes
Digital Noise Reduction    Yes
Motion Detection Tracking    Yes
Privacy Masking    Yes
Wide Dynamic Range    Yes
Mirror    Yes
ONVIF  Yes
