Luminys N4T-4VA2 4 Megapixel Network IP LumiNightKing Turret Camera with 2.8mm Lens
SKU
N4T-4VA2
Model No
N4T-4VA2
$203.41
Product Highlights
- 4MP Turret Housing
- 2.8 mm Lens
- AI-ISP
- White-Light LEDs
- Video Content Analytics: Line Crossing, Intrusion
Speak to an expert
The N4T-4VA2 is part of Luminys’s N4 Mainstream series of security devices, designed with advanced LumiTechnologies to meet today’s evolving security needs. Equipped with LumiNightKing technology, it offers full-color video in low-light conditions, covert monitoring, and exceptional environmental resilience. Ideal for mission-critical surveillance in various challenging environments, it balances discrete operation with visible deterrence.
Luminys N4T-4VA2 Camera Features
- 4MP Turret Housing: High-resolution imaging enables detailed surveillance, capturing clearer and more accurate footage.
- 2.8 mm Lens: Provides a wide field of view for optimal coverage of large areas.
- AI-ISP: Intelligent image signal processing enhances image quality and allows for advanced video analytics.
- White-Light LEDs: Offers effective deterrent capabilities while providing illumination for high-quality night vision.
- Video Content Analytics: Features like Line Crossing and Intrusion alerts enhance security with proactive monitoring.
- iMD: Intelligent Motion Detection technology reduces false alarms, ensuring efficient surveillance.
Detailed Camera Specifications for Luminys N4T-4VA2
| Feature | Details |
|---|---|
| Resolution | 4MP |
| Lens Type | 2.8 mm |
| Power Options | 12 VDC and PoE |
| Operating Temperature | Extremely rugged environments |
| Night Vision Technology | LumiNightKing for full-color video in low light |
| Analytics Features | Line Crossing, Intrusion detection |
SKU  | N4T-4VA2 |
|---|---|
| Features | Audio, Auto Gain Control, Day/Night, Digital Noise Reduction, Mirror, Motion Detection Tracking, ONVIF, Privacy Masking, Weather Resistant, Wide Dynamic Range |
| Manufacturer | Luminys |
| NDAA | Compliant |
Camera Signal  | Network IP |
| Connection Type | Wired |
| Infrared Distance | 61~100 Feet |
| Resolution | 4 Megapixel |
| Lens Type | Fixed |
| Lens Size | 2.8mm |
| Mount Type | Ceiling, Pole, Wall |
| Compression Method | H.264, M-JPEG, H.265, H.264+, H.265+ |
| Durability | Weather Resistant |
| Voltage | 12vDC, PoE |
| Dimensions (W x H) | Φ122.0 mm x 111.8 mm (Φ4.8 in. x 4.4 in.) |
| Electronic Shutter | Automatic, Manual 1/3 s to 1/100,000 s |
| Image Device | 1/1.8-in. 4MP Progressive CMOS |
| Minimum Scene Illumination | Color: 0.0006 lux at F1.0 |
| Operating Humidity | < 95% RH (Non-Condensing) |
| Operating Temperature | -40 to 60 °C (-40 to 140 °F) |
| Power Consumption | 12 VDC: Maximum: 5.3 W, Normal: 2.0 W , PoE: Maximum: 6.4 W, Normal: 2.5 W |
| Protocols | IPv4, IPv6, DNS, TCP, UDP, DHCP, HTTP, HTTPS, 802.1X, RTSP, DDNS, P2P, SMTP, RTMP, PPPoE, UPnP, SNMP, Bonjour, QoS, Auto Registration, ICMP, IGMP, FTP, SFTP, RTP, RTCP, ARP, NTP, Multicast, NFS |
| S/N Ratio | > 50 dB |
| Weatherproof | IP67 |
| Digital Noise Reduction | 3D NR |
| Mirror | Supported |
| Angle of View | Horizontal: 112° , Vertical: 60° , Diagonal: 134° |
| Rotation Angle | 0° to 360° |
| Motion Detection Tracking | Supported with Alarms for Vehicles and Humans |
| IR Distance | 30.48m/100ft |
| Audio | Yes |
| Auto Gain Control | Yes |
| Day/Night | Yes |
| Digital Noise Reduction | Yes |
| Motion Detection Tracking | Yes |
| Privacy Masking | Yes |
| Wide Dynamic Range | Yes |
| Mirror | Yes |
| ONVIF | Yes |
