Panasonic M-46-V-V2 4 Megapixel Network Outdoor Dome Camera with 2.8-12mm Lens
SKU
M-46-V-V2
Model No
M-46-V-V2
$290.92
Product Highlights
- 4MP (2688 x 1520)
- 2.8-12mm motorized lens
- Built-in IR-LED up to 40 m (131 ft.)
- WDR 120dB
- H.265, H.264 and MJPEG
Speak to an expert
The Panasonic M-46-V-V2 is a powerful 4 Megapixel network outdoor dome camera designed for high-performance surveillance. With a varifocal 2.8-12mm lens, this camera delivers exceptional image quality even in challenging lighting conditions, making it ideal for various outdoor applications. Its robust construction and advanced features ensure reliable security monitoring for any environment.
Panasonic M-46-V-V2 Camera Features
- High Resolution: 4MP (2688 x 1520) delivers clear and detailed images for superior surveillance capabilities.
- Flexible Lens Options: 2.8-12mm motorized lens allows for versatile viewing angles, making it adaptable for different installation scenarios.
- Enhanced Night Vision: Built-in IR-LED illuminates up to 40 m (131 ft.), ensuring reliable monitoring even in complete darkness.
- Advanced WDR: WDR 120dB technology provides superior image quality in scenes with extreme lighting variations.
- Versatile Compression Formats: Supports H.265, H.264, and MJPEG, optimizing storage and bandwidth usage while maintaining video quality.
- Audio Capture: Built-in microphone enables audio monitoring to complement video surveillance for a comprehensive security solution.
- Robust Build Quality: IP67 and IK10 ratings ensure the camera is resistant to water, dust, and impacts, perfect for outdoor use.
- Interoperability: ONVIF Profile G, S, T compliance ensures compatibility with various surveillance systems for easy integration.
- NDAA Compliant: Meets the National Defense Authorization Act standards for enhanced security assurance.
Detailed Camera Specifications for Panasonic M-46-V-V2
| Feature | Details |
| Resolution | 4MP (2688 x 1520) |
| Lens Type | Varifocal 2.8-12mm motorized |
| Night Vision | Built-in IR-LED, up to 40 m (131 ft.) |
| WDR | 120dB |
| Compression Formats | H.265, H.264, MJPEG |
| Audio | Built-in Microphone |
| Ingress Protection | IP67 |
| Impact Resistance | IK10 |
| ONVIF Compliance | Profile G, S, T |
| NDAA Compliant | Yes |
SKU  | M-46-V-V2 |
|---|---|
| Features | Audio, Auto Gain Control, Automatic White Balance, Back Light Compensation, Motion Detection Tracking, ONVIF, Privacy Masking, Vandal Resistant, Weather Resistant, Wide Dynamic Range |
| Manufacturer | Panasonic |
| NDAA | Compliant |
| Connection Type | Wired |
Infrared Distance  | 101 Feet + |
| Resolution | 4 Megapixel |
| Lens Type | Varifocal |
| Lens Size | 2.8-12mm |
| Mount Type | Ceiling, Wall |
| Compression Method | H.264, M-JPEG, H.265 |
| Durability | Vandal Resistant, Weather Resistant |
| Voltage | 12vDC, PoE |
| Dimensions (W x H) | ø128 x 100mm (Ø5.0” x 3.9”) |
| Electronic Shutter | Auto/Manual, 1 - 1/100000s |
| Image Device | 1/3" Progressive Scan CMOS |
| IR LEDs | Up to 40m (131ft.), Wavelength: 850nm |
| Minimum Scene Illumination | Color: 0.003Lux (F1.6, AGC ON) | 0Lux with IR |
| Operating Humidity | ≤95% RH (non-condensing) |
| Operating Temperature | -30°C ~ 60°C (-22°F ~ 140°F), |
| Power Consumption | Max. 8.0W |
| Privacy Zone | Up to 4 areas |
| S/N Ratio | > 52 dB |
| Weatherproof | IP66 |
| Angle of View | H: 86.3° - 35.2°, V: 47.1° - 17.0°, D: 91.9° - 38.6° |
| IR Distance | 40m/131ft |
| Audio | Yes |
| Auto Gain Control | Yes |
| Digital Noise Reduction | Yes |
| Automatic White Balance | Yes |
| Back Light Compensation | Yes |
| Motion Detection Tracking | Yes |
| Privacy Masking | Yes |
| Wide Dynamic Range | Yes |
| ONVIF | Yes |
