Panasonic M-46-FW-V3 4 Megapixel Network IP Advidia Outdoor IR Dome Camera with 2.8mm Lens
SKU
M-46-FW-V3
Model No
M-46-FW-V3
$308.41
Product Highlights
- 4MP (2688 x 1520)
- True WDR 120dB
- 2.8mm Fixed lens
- H.265, H.264, MJPEG
- Support 9:16 Corridor Mode
Speak to an expert
The Panasonic M-46-FW-V3 Advidia Outdoor IR Dome Camera delivers 4MP high-definition video with a 2.8mm fixed lens for wide-area coverage. Equipped with infrared night vision, weather-resistant construction, and intelligent network features, this IP camera provides reliable surveillance performance for outdoor commercial and residential security applications.
Features
- 4MP (2688 x 1520)
- True WDR 120dB
- 2.8mm Fixed lens
- H.265, H.264, MJPEG
- Support 9:16 Corridor Mode
- IP67, IK10
- Built-in Microphone
- NDAA Compliant
- ONVIF Profile G, S, T
SKU  | M-46-FW-V3 |
|---|---|
| Features | Audio, Auto Gain Control, Automatic White Balance, Back Light Compensation, Day/Night, Digital Noise Reduction, Motion Detection Tracking, ONVIF, Privacy Masking, Vandal Resistant, Weather Resistant, Wide Dynamic Range |
| Manufacturer | Panasonic |
| NDAA | Compliant |
Camera Signal  | Network IP |
| Connection Type | Wired |
| Infrared Distance | 61~100 Feet |
| Resolution | 4 Megapixel |
| Lens Type | Fixed |
| Lens Size | 2.8mm |
| Mount Type | Ceiling, Wall |
| Compression Method | H.264, M-JPEG, H.265 |
| Durability | Vandal Resistant, Weather Resistant |
| Voltage | 12vDC, PoE |
| Dimensions (W x H) | Φ111 x 83mm (Ø4.4” x 3.3”) |
| Electronic Shutter | Auto/Manual, 1 ~ 1/100000s |
| Image Device | 1/2.7", 5.0 Megapixel, Progressive Scan, CMOS |
| Minimum Scene Illumination | Color: 0.003Lux (F1.6, AGC ON) | 0Lux with IR on |
| Operating Humidity | ≤95% RH (Non-Condensing) |
| Operating Temperature | -30°C ~ 60°C (-22°F ~ 140°F) |
| Power Consumption | Max 4.4W |
| Protocols | IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, RTMP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, SSL/TLS, 802.1x, SNMP |
| S/N Ratio | >52dB |
| Weatherproof | IP67, IK10 |
| Angle of View | H: 110.0° | V: 58.7° | O: 130° |
| Rotation Angle | 10° ~ 360° |
| IR Distance | 30m/98ft |
| Audio | Yes |
| Auto Gain Control | Yes |
| Day/Night | Yes |
| Digital Noise Reduction | Yes |
| Automatic White Balance | Yes |
| Back Light Compensation | Yes |
| Motion Detection Tracking | Yes |
| Privacy Masking | Yes |
| Wide Dynamic Range | Yes |
| ONVIF | Yes |
