KT&C KPC-HDN720M IR Bullet Type HDcctv Camera

SKU: KPC-HDN720M

Model #: KPC-HDN720M

by KT&C
  • KT&C  KPC-HDN720M IR Bullet Type HDcctv Camera KT&C  KPC-HDN720M IR Bullet Type HDcctv Camera

SKU: KPC-HDN720M

Model #: KPC-HDN720M

Availability: Usually ships the next business day

Call for Pricing

800.955.5201

Low Price Guarantee

Availability: Usually ships the next business day

Availability: Usually ships the next business day

  • Express Checkout:

Product Details

The KPC-HDN720M from KT&C is an IR Bullet Type HDcctv Camera with 1 / 2.8” Sony Exmor Progressive Color CMOS, DC 12V / AC 24V Dual Voltage, 45 Units IR LED with Max. 150ft, HD-SDI (BNC).

Features

  • 1 / 2.8” Sony Exmor Progressive Color CMOS
  • 1920 x 1080 (1080p@60fps, 50fps, 30fps, 25fps)
  • HD-SDI (BNC)
  • TV Out (BNC), NTSC / PAL Selectable
  • SN Ratio : Max. 50dB
  • 45 Units IR LED with Max. 150ft
  • True Mechanical Day & Night
  • Mega Pixel Varifocal Lens (3.6~16mm)
  • AWB, AGC, BLC
  • Convenient OSD
  • Second Video Output
  • DC 12V / AC 24V Dual Voltage

Product Specs

SKU  KPC-HDN720M
Manufacturer  KT&C
Features  Auto Gain Control, Automatic White Balance, Back Light Compensation, Day/Night, Flickerless, On Screen Display Menu, Weather Resistant
Camera Signal    HD-SDI
Resolution   2.1 Megapixel
Sensor Option   1/2.8" CMOS
Lens Type   Varifocal
Lens Size   3.6-16mm
Infrared Distance   101 Feet +
Durability   Weather Resistant
Mount Type  Ceiling, Wall
Voltage  12vDC, 24vAC
Image Device   1 / 2.8” 2.1MP SONY Exmor Progressive CMOS
Image Pixels-Effective 2096(H)x1561(V)
IR Distance  Up to 150ft
IR Wavelength  850 nm
Minimum Scene Illumination  0 Lux (IR LED On)
Operating Humidity   Less than 80%
Operating Temperature   -10 °C ~ 50 °C (14 °F ~ 122 °F)
Dimensions (W x H)  80.6 ? x 168.6 mm
OSD Menu   Built-in
Power Consumption  12VDC: Max. 1100 mA, 24VAC: Max. 12 W
S/N Ratio  Max 50dB
Signal System   TV Out : NTSC / PAL selectable
Weatherproof   IP67
Backlight Compensation   On / Off
Automatic White Balance   Manual / ATW / Push
IR LEDs  45 IR LEDs
Flickerless   Off / 50Hz / 60Hz
Back Light Compensation   Yes
Automatic White Balance   Yes
Day/Night   Yes
On Screen Display Menu   Yes
Auto Gain Control   Yes
Flickerless   Yes
