ACTi K71 2 Megapixel Network IP Outdoor IR Dome Camera with 2.8mm Lens
Model No
K71
$286.20
Product Highlights
- 2 Megapixel, f2.8mm, Fixed Dome
- IR LED 50m, Extreme WDR (130 dB)
- Color Min. Illumination 0.003 lux
- Smart Motion Detection
- DORI (42.0 / 16.8 / 8.4 / 4.2m)
Speak to an expert
The ACTi K71 2 Megapixel Network IP Outdoor IR Dome Camera is designed to deliver exceptional surveillance performance with cutting-edge features. Equipped with a 2.8mm lens and advanced IR capabilities, this camera ensures clear and reliable monitoring for outdoor areas, even in low-light conditions. Its smart motion detection and extreme WDR technology enhance security by providing sharp and detailed images, making it a perfect choice for various surveillance applications.
ACTi K71 Camera Features
- 2 Megapixel, f2.8mm, Fixed Dome: Offers high-resolution images, ensuring detailed surveillance for enhanced security monitoring.
- IR LED 50m, Extreme WDR (130 dB): Provides excellent night vision up to 50 meters while effectively balancing extreme lighting conditions for clearer images.
- Color Min. Illumination 0.003 lux: Allows full-color video capture in extremely low light, ensuring reliable performance even at night.
- Smart Motion Detection: Enhances efficiency by reducing false alarms and focusing on real threats, saving time and resources.
- DORI (42.0 / 16.8 / 8.4 / 4.2m): Ensures comprehensive coverage for various distances, allowing for tailored surveillance setups based on area requirements.
Detailed Specifications for ACTi K71
| Feature | Details |
|---|---|
| Model | ACTi K71 |
| Resolution | 2 Megapixel |
| Lens | 2.8mm Fixed Dome |
| Night Vision | IR LED Range: 50m |
| Wide Dynamic Range | Extreme WDR: 130 dB |
| Low Light Performance | Min. Illumination: 0.003 lux |
| Smart Features | Smart Motion Detection |
| DORI Coverage | 42.0 / 16.8 / 8.4 / 4.2m |
SKU  | K71 |
|---|---|
| Features | Audio, Auto Gain Control, Automatic White Balance, Back Light Compensation, Day/Night, Digital Noise Reduction, Mirror, Motion Detection Tracking, ONVIF, Privacy Masking, Vandal Resistant, Weather Resistant, Wide Dynamic Range |
| Manufacturer | ACTi |
| NDAA | Compliant |
Camera Signal  | Network IP |
| Connection Type | Wired |
| Infrared Distance | 101 Feet + |
| Resolution | 2 Megapixel |
| Lens Type | Fixed |
| Lens Size | 2.8mm |
| Mount Type | Ceiling, Wall |
| Compression Method | H.264, M-JPEG, H.265 |
| Durability | Vandal Resistant, Weather Resistant |
| Voltage | 12vDC, PoE |
| Dimensions (W x H) | (Ø x H): 109mm x 83mm (4.3" x 3.3") |
| Electronic Shutter | 1-1/100000 second (manual mode); 1-1/100000 second (auto mode) |
| Image Device | 1/2.7 " Progressive Scan CMOS |
| IR LEDs | Adaptive IR LED |
| IR Wavelength | 850 nm |
| Minimum Scene Illumination | Color: 0.003 lux at F2.0 (AGC on); B/W: 0 lux (IR LED on) |
| Operating Humidity | 10% - 95% RH, non-condensing |
| Operating Temperature | -30°C ~ 60°C (-22°F ~ 140°F) |
| Power Consumption | 3.5 W (PoE) |
| Protocols | IPv4, TCP, UDP, DHCP, HTTP, HTTPS, DNS, DDNS, NTP, RTP, RTSP, RTCP, RTMP, SMTP, FTP, IGMP, ICMP, ARP, UPnP, SNMP, SSL, QoS, TLS 1.2 |
| S/N Ratio | 75 dB |
| Weatherproof | IP68, IK10 |
| Digital Noise Reduction | 2D + 3D DNR |
| Angle of View | Horizontal Viewing Angle 112.9° Vertical Viewing Angle 59.1° |
| Rotation Angle | 0°-360° |
| IR Distance | 50m/164ft |
| Audio | Yes |
| Auto Gain Control | Yes |
| Day/Night | Yes |
| Digital Noise Reduction | Yes |
| Automatic White Balance | Yes |
| Back Light Compensation | Yes |
| Motion Detection Tracking | Yes |
| Privacy Masking | Yes |
| Wide Dynamic Range | Yes |
| Mirror | Yes |
| ONVIF | Yes |
