Pelco IS21-CHV10F Camclosure-2 Indoor Mini Dome Camera, Clear Bubble, Flush, NTSC

SKU
IS21-CHV10F
Model No
IS21-CHV10F
$34.99
Volume Discounts Volume
Discounts
Free System Design Free System
Design
Lifetime Tech Support Lifetime
Tech Support
Free Shipping Over $450* Free Shipping
Over $450*
Product Highlights
  • Fully Integrated Indoor Enclosure with Camera and Lens
  • Varifocal Lens
  • Shipped Completely Assembled, Easy to Install
  • 24 VAC or 12 VDC Operation, Autosensing
  • Service Connector for Video Output

The Pelco IS21-CHV10F Indoor Mini Dome Camera is an advanced surveillance solution engineered for high-level monitoring in a multitude of environments. Equipped with features such as a 1/3 inch CCD sensor, automatic back focus, and a wide dynamic range, this camera ensures crystal clear video quality even in challenging lighting conditions, making it ideal for effective security management.

Pelco IS21-CHV10F Camera Features

  • High Resolution: With 650 TV lines, this camera delivers sharp and detailed images crucial for security monitoring.
  • Low Light Performance: Provides effective surveillance even in low illumination environments with a sensitivity of 0.6 lux.
  • Auto Image Stabilizer: Ensures steady imaging by compensating for external vibrations, which is essential for clear recordings.
  • Wide Dynamic Range: Captures clear details in both bright and dark areas of the image, providing a balanced view of the scene.
  • Various Mounting Options: Available in surface or flush mount designs and compatible with both smoked and clear domes, ensuring versatility in installation.
  • Easy Installation: The camera comes completely assembled with a service connector for simple video output setup.

Pelco IS21-CHV10F Detailed Camera Specifications

Camera Type Indoor Mini Dome Camera
Sensor Type 1/3 Inch Interline Transfer CCD
Resolution 650 TV Lines
Lux Rating 0.6 Lux
Zoom Capability 3.6x Zoom
Power Requirements 24 VAC or 12 VDC, Autosensing
Scanning System 2:1 Interlace
Dynamics Wide Dynamic Range
SKU  IS21-CHV10F
Features  Auto Gain Control, Automatic White Balance, Day/Night, Motion Detection Tracking, On Screen Display Menu, Wide Dynamic Range
Manufacturer  Pelco
NDAACompliant
Camera Signal     Analog
Resolution    540 TVL
Sensor Option    1/3" CCD
Lens Type    Varifocal
Lens Size    2.8-10mm
Infrared Distance    Non Infrared
Durability    Indoor
Mount Type  Ceiling, Wall
Voltage  12vDC, 24vAC
Image Device    1/3-inch Interline transfer CCD
Image Pixels-Effective768 (H) x 494 (V)
Minimum Scene Illumination  0.6 lux (color mode), 0.4 lux (B-W mode)
Operating Humidity    Less than 90%
Operating Temperature    14° to 122°F (–10° to 50°C)
Power Consumption  2.7W
S/N Ratio  50 dB (equivalent to AGC Off, weight On)
Scanning System    2:1 interlace
Signal System    NTSC
Video Output    1.0 Vp-p, NTSC/PAL composite, 75 ohms, BNC connector
Synchronization  Internal
Angle of View    100.2° wide zoom; 27.4° telephoto zoom, 73.3° wide zoom; 20.3° telephoto zoom
Automatic White Balance    Auto Tracking White Balance/Automatic White Balance Control
Automatic White Balance    Yes
Day/Night    Yes
On Screen Display Menu    Yes
Wide Dynamic Range    Yes
Auto Gain Control    Yes
Motion Detection Tracking    Yes
There are no related videos.

4

1 reviews

Write a review

Share your thoughts with other customers

Top customer reviews

  1. Ron d.

    Verified Buyer

    it works great, the price 0 people found this helpful

    it works great, the price i paid for the quality i get I’m happy.
    Was this review helpful?
Write Your Own Review
You're reviewing:Pelco IS21-CHV10F Camclosure-2 Indoor Mini Dome Camera, Clear Bubble, Flush, NTSC
Your Rating
Manuals & Specifications
  IS21-CHV10F-Specsheet
  IS21-CHV10F-Installation
