ICRealtime IPEL-D40V-W1-LED 4 Megapixel Network IR Outdoor Dome Camera with 2.7-12mm Lens
SKU
IPEL-D40V-W1-LED
Model No
IPEL-D40V-W1-LED
$658.00
Product Highlights
- 4MP 1/1.8" CMOS image sensor, low illuminance, high image definition
- H.265 & H.264 triple-stream encoding
- 2.7-12mm Varifocal lens, 4MP (2688 × 1520)@30 fps
- IVS, Intelligent Motion Detect, Perimeter Protection
- WDR(140dB), 3D DNR, HLC, BLC
Speak to an expert
IC Realtime's IPEL-D40V-W1-LED puts advanced surveillance at your fingertips, delivering stunning full-color video from day to night. With an IK10-rated vandal-proof dome design, this 4 Megapixel Network IR Outdoor Dome Camera ensures durability while providing crystal-clear images, even in ultra-low light conditions. Its intelligent features like Motion Detect and Perimeter Protection reduce false alerts, making it an exceptional choice for security needs that demand reliability and performance.
ICRealtime IPEL-D40V-W1-LED Camera Features
- 4MP Image Sensor: Experience low illuminance and high definition for crystal-clear video.
- H.265 & H.264 Encoding: Efficient compression allows for high-quality video streaming and storage.
- Varifocal Lens: The 2.7-12mm lens provides flexibility for various surveillance scenarios at 30 fps.
- Advanced Motion Detection: Intelligent Motion Detect and Perimeter Protection minimize false alarms for accurate monitoring.
- Wide Dynamic Range: With 140dB WDR, enjoy vivid images in challenging lighting conditions.
- Audio Integration: Built-in microphone and speakers enhance communication and monitoring capabilities.
- Enhanced Illumination: Warm light LEDs provide up to 131ft of full-color illumination in dark environments.
- Durability: Features such as IP67 weatherproofing and IK10 vandal resistance ensure long-term reliability.
Detailed Specifications for ICRealtime IPEL-D40V-W1-LED
| Camera Type | 4 Megapixel Network IR Outdoor Dome Camera |
| Image Sensor | 1/1.8" low illuminance CMOS |
| Video Resolution | 2688 - 1520 @ 30 fps |
| Lens Type | 2.7-12mm motorized varifocal lens |
| Encoding Formats | H.265, H.264 triple-stream encoding |
| Illumination Range | Up to 131 feet with warm light LEDs |
| Dynamic Range | 140dB WDR |
| Audio Support | Built-in Mic, Speakers, 1 input/1 output Alarm |
| Storage Support | 256GB Micro SD |
| Weatherproof Rating | IP67 |
| Vandal Resistance | IK10 |
| Power Supply | PoE, ePOE support |
SKU  | IPEL-D40V-W1-LED |
|---|---|
| Features | Audio, Auto Gain Control, Automatic White Balance, Back Light Compensation, Day/Night, Digital Noise Reduction, Mirror, Motion Detection Tracking, ONVIF, Privacy Masking, Vandal Resistant, Weather Resistant, Wide Dynamic Range |
| Manufacturer | ICRealtime |
Camera Signal  | Network IP |
| Connection Type | Wired |
| Infrared Distance | 101 Feet + |
| Resolution | 4 Megapixel |
| Lens Type | Varifocal |
| Lens Size | 2.7-12mm |
| Mount Type | Ceiling, Wall |
| Compression Method | H.264B, H.264H, H.264, M-JPEG, H.265 |
| Durability | Vandal Resistant, Weather Resistant |
| Voltage | 12vDC, PoE |
| Automatic Gain Control (AGC) | Auto / Manual |
| Dimensions (W x H) | 4.1" × 5.0" (105 mm × 126 mm) |
| Electronic Shutter | Auto/Manual 1/3 s–1/100,000 s |
| Image Device | 1/1.8” CMOS |
| Image Pixels-Effective | 2688 (H) ×1520 (V) |
| Minimum Scene Illumination | [email protected] |
| Power Consumption | Basic: 2.3 W (12 VDC); 3.3 W (PoE) Max. (H.265 + 3 streams + intelligence + LED): 7.4 W (12 VDC); 9.0 W (PoE) |
| Privacy Zone | 8 areas |
| Protocols | IPv4;IPv6;HTTP;HTTPS;TCP;UDP;ARP;RTP;RTSP;RTCP; RTMP;SMTP;FTP;SFTP;DHCP;DNS;DDNS;QoS;UPnP;N TP;Multicast;ICMP;IGMP;NFS;PPPoE;802.1x;SNMP |
| S/N Ratio | > 56 dB |
| Weatherproof | IP67 |
| Digital Noise Reduction | 3D DNR |
| Angle of View | Horizontal: 115°–48°, Vertical: 59°–27° |
| Automatic White Balance | Auto/natural/street lamp/outdoor/manual/regional custom |
| IR Distance | 39m/131ft |
| Audio | Yes |
| Auto Gain Control | Yes |
| Day/Night | Yes |
| Digital Noise Reduction | Yes |
| Automatic White Balance | Yes |
| Back Light Compensation | Yes |
| Motion Detection Tracking | Yes |
| Privacy Masking | Yes |
| Wide Dynamic Range | Yes |
| Mirror | Yes |
| ONVIF | Yes |
