TP-Link INSIGHT-S485PI 8 Megapixel Network IP VIGI IR Panoramic Turret Camera with 1.65mm Lens
SKU
INSIGHT-S485PI
Model No
INSIGHT-S485PI
$446.45
Product Highlights
- 180° Panorama View with Huge Vision
- 4K (8MP) Ultra HD and IR Range Up to 65.62 ft (20 m)
- Red-Blue Warning Lights with Stronger Deterrence
- People & Vehicle Analytics
- Human & Vehicle Classification
Speak to an expert
The TP-Link INSIGHT-S485PI 8 Megapixel Network IP VIGI IR Panoramic Turret Camera is an advanced security solution designed for comprehensive surveillance needs. With its 180° panoramic view and stunning 4K resolution, it ensures every detail is captured with clarity. Key benefits include enhanced deterrence with integrated warning lights and sophisticated analytics that differentiate between people and vehicles, making it an ideal choice for both residential and commercial security.
TP-Link INSIGHT-S485PI Camera Features
- 180° Panorama View: Provides a wide field of vision, reducing the number of cameras needed for complete coverage.
- 4K (8MP) Ultra HD: Delivers exceptionally detailed images, ensuring that critical details are visible and identifiable.
- IR Range Up to 65.62 ft (20 m): Offers clear night vision capabilities, enhancing security in low-light conditions.
- Red-Blue Warning Lights: Increases deterrence against potential intruders by visibly alerting them to surveillance.
- People & Vehicle Analytics: Utilizes advanced algorithms to provide real-time data insights, improving security response times.
TP-Link INSIGHT-S485PI Camera Specifications
| Camera Type | Panoramic Turret |
| Megapixels | 8MP (4K) |
| Viewing Angle | 180° |
| IR Distance | Up to 65.62 ft (20 m) |
| Analytics | People and Vehicle Classification |
| Warning Lights | Red-Blue Integrated Lights |
SKU  | INSIGHT-S485PI |
|---|---|
| Features | Audio, Auto Gain Control, Automatic White Balance, Back Light Compensation, Coaxitron, Day/Night, Digital Noise Reduction, Mirror, Motion Detection Tracking, ONVIF, Privacy Masking, Vandal Resistant, Weather Resistant, Wide Dynamic Range, 4K Resolution |
| Manufacturer | TP-Link |
Camera Signal  | Network IP |
| Connection Type | Wired |
| Infrared Distance | 61~100 Feet |
| Resolution | 8 Megapixel |
| Lens Type | Fixed |
| Lens Size | 1.65mm |
| Mount Type | Ceiling, Wall |
| Compression Method | H.264, H.265, H.264+, H.265+ |
| Durability | Vandal Resistant, Weather Resistant |
| Voltage | 12vDC, PoE |
| Dimensions (W x H) | 4.4 × 4.4 × 4.3 in (112.3 × 112.3 × 110.2 mm) |
| Electronic Shutter | 1/3 to 1/10000 s |
| Image Device | 1/2.7” Progressive Scan CMOS |
| IR LEDs | 4 |
| IR Wavelength | 850nm |
| Minimum Scene Illumination | 0.005 Lux; 0 Lux with IR Light |
| Operating Humidity | 95% or Less (Non-Condensing) |
| Operating Temperature | -30 °C to 60 °C |
| Protocols | TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP |
| S/N Ratio | ≥ 52 dB |
| Weatherproof | IP67, IK10 |
| Angle of View | Horizontal FOV: 180° , Vertical FOV: 86° , Diagonal FOV: 180° |
| Rotation Angle | 0° to 360° |
| IR Distance | 20m/65.62ft |
| Audio | Yes |
| Auto Gain Control | Yes |
| Day/Night | Yes |
| Digital Noise Reduction | Yes |
| Automatic White Balance | Yes |
| Back Light Compensation | Yes |
| Motion Detection Tracking | Yes |
| Privacy Masking | Yes |
| Wide Dynamic Range | Yes |
| Mirror | Yes |
| ONVIF | Yes |
