Pelco IDL302-FXI 3 Megapixel Network Bullet Camera with 2.8mm Lens
SKU
IDL302-FXI
Model No
IDL302-FXI
$209.75
Product Highlights
- Flexible design and installation options
- Multiple form factors and resolutions
- Smart Analytics, powered by Motorola Solutions
- H.264 and H.265 Smart Compression technology
- Operating Temperature: -10 °C to +60 °C (14 °F to 140 °F)
Speak to an expert
The Pelco IDL302-FXI is a versatile 3-megapixel network bullet camera designed for optimal performance in discreet monitoring scenarios. With built-in analytic capabilities and a flexible modular design, this camera enhances security by providing real-time responses and simplifying forensic investigations, making it ideal for spaces such as ATMs, police interview rooms, and retail environments.
Pelco IDL302-FXI Camera Functions
- 3 Megapixel Clarity: Offers high-resolution imaging for clear visibility in diverse lighting conditions, enhancing security monitoring.
- Adjustable Imager Modules: Allows flexible positioning for optimal views, catering to limited or unique spaces.
- Pelco Smart Analytics: Enhances security team efficiency by providing real-time alerts and improving response times.
- NDAA Compliant: Ensures open connectivity with various video management systems for streamlined operations.
- Robust Operating Range: Functions effectively in temperatures from -10 °C to +60 °C (14 °F to 140 °F), making it suitable for various environments.
Detailed Camera Specifications
| Specification | Details |
|---|---|
| Resolution | 3 Megapixels |
| Lens | 2.8mm |
| Dynamic Range | Up to 130 dB True Wide Dynamic Range |
| Compression | H.264 and H.265 Smart Compression |
| Smart Analytics | Powered by Motorola Solutions |
| Compliance | ONVIF Profile S, G, and T |
| Temperature Range | -10 °C to +60 °C (14 °F to 140 °F) |
| Mounting Options | Various options available for flexible installation |
SKU  | IDL302-FXI |
|---|---|
| Features | Audio, Auto Gain Control, Automatic White Balance, Back Light Compensation, Day/Night, Digital Noise Reduction, Flickerless, Motion Detection Tracking, ONVIF, Privacy Masking, Wide Dynamic Range |
| Manufacturer | Pelco |
Camera Signal  | Network IP |
| Connection Type | Wired |
| Infrared Distance | Non Infrared |
| Resolution | 3 Megapixel |
| Lens Type | Fixed |
| Lens Size | 2.8mm |
| Mount Type | Bracket Required |
| Compression Method | H.264, M-JPEG, H.265 |
| Voltage | 12vDC, PoE |
| Dimensions (W x H) | 45 mm x 25 mm x 20 mm; 1.77 ” x 0.98 ” x 0.79 ” |
| Electronic Shutter | Automatic, Manual (1/7.5 to 1/8000 sec) |
| Image Device | 1/2.7 ” Progressive Scan |
| Minimum Scene Illumination | 0.1 lux |
| Operating Humidity | 0 - 100% RH |
| Operating Temperature | -30 °C to +60 °C (-22 °F to 140 °F) |
| Power Consumption | 13 W Max |
| Privacy Zone | Up to 64 zones |
| Protocols | IPv4, IPv6, HTTP, HTTPS, SOAP, DNS, NTP, RTSP, RTCP, RTP, TCP, UDP, IGMPv2, ICMP, DHCP, Zeroconf, ARP |
| Weatherproof | IP66 |
| Digital Noise Reduction | 3D |
| Angle of View | Horizontal Angle of View: (4:3) 110 °, Vertical Angle of View: (4:3) 80 ° |
| Flickerless | 60 Hz, 50 Hz |
| Back Light Compensation | Adjustable |
| Automatic White Balance | Automatic, Manual |
| Audio | Yes |
| Auto Gain Control | Yes |
| Day/Night | Yes |
| Digital Noise Reduction | Yes |
| Automatic White Balance | Yes |
| Back Light Compensation | Yes |
| Flickerless | Yes |
| Motion Detection Tracking | Yes |
| Privacy Masking | Yes |
| Wide Dynamic Range | Yes |
| ONVIF | Yes |
