Speco HTB10X 580 TVL Outdoor Bullet Camera with 10x Motorized Zoom Lens
SKU
HTB10X
Model No
HTB10X
$834.89
Product Highlights
- 580/560 lines of resolution
- 3.8-38mm motorized auto iris varifocal lens
- Minimum illumination 0 lux with 30 IR LEDs
- Adjustable IR brightness
- 40M IR range
Speak to an expert
The HTB10X from Speco is a 580 TVL outdoor bullet camera equipped with a versatile 10x motorized zoom lens. This camera delivers exceptional image quality, robust performance in harsh environments, and flexible installation options, making it ideal for both residential and commercial security applications.
Speco HTB10X Camera Features
- Resolution: 580 TVL for clear and detailed images, ensuring effective surveillance.
- Lens: 3.8-38mm motorized auto iris varifocal lens that allows for versatile focal length adjustments for various monitoring scenarios.
- Illumination: Minimum illumination of 0 lux with 30 IR LEDs for outstanding night vision capabilities, providing 24/7 surveillance.
- IR Range: 40M IR range that enhances visibility in low-light conditions, ensuring comprehensive coverage.
- Power Compatibility: Dual voltage 12V DC & 24V AC operation for flexible power options in various installations.
- Full OSD Operation: Allows for user-friendly adjustments of camera settings through an on-screen display.
- Easy Adjustment: All controls are easily accessible for quick and straightforward adjustments.
- Weatherproof: Designed for outdoor use, ensuring reliable operation in various weather conditions.
- Zoom Capabilities: 10X optical & digital zoom providing the ability to get closer to the action without losing image quality.
- Cooling System: Built-in fan to maintain optimal operating temperatures, prolonging camera lifespan.
- Mounting Options: Wall & ceiling mountable for versatile installation in different settings.
Speco HTB10X Detailed Specifications
| Resolution | 580 TVL |
| Lens Type | 3.8-38mm motorized auto iris varifocal |
| Minimum Illumination | 0 lux with 30 IR LEDs |
| IR Range | 40M |
| Power Supply | 12V DC & 24V AC |
| OSD Operation | Full OSD functionality |
| Weatherproof | Yes |
| Zoom | 10X optical & digital |
| Cooling System | Built-in fan |
| Mounting Options | Wall & ceiling |
SKU  | HTB10X |
|---|---|
| Features | Auto Gain Control, Digital Zoom, On Screen Display Menu, Weather Resistant |
| Manufacturer | Speco |
Camera Signal  | Analog |
| Resolution | 580 TVL |
| Sensor Option | 1/4" CCD |
| Lens Type | Motorized Zoom |
| Lens Size | 10X |
| Infrared Distance | 101 Feet + |
| Durability | Weather Resistant |
| Mount Type | Ceiling, Wall |
| Voltage | 24vAC |
| Electronic Shutter | Auto: 1/60 ~1/100,000 sec., Manual: 1/60, FLK(1/120), 1/250, 1/500, 1/1,000, 1/2,000, 1/4,000, 1/10,000 |
| Image Device | 1/4" Sony Super-HAD CCD |
| Image Pixels Total | 410K |
| IR Distance | 40m/131ft |
| Minimum Scene Illumination | 0.1 Lux (F1.8) LED OFF / 0 Lux (40M range) LED ON |
| Operating Temperature | -20°F to 122°F (with fan: -68°F to 140°F) |
| Dimensions (W x H) | 3.1”W x 3” H x 6.8” L |
| Power Consumption | 600mA Max. |
| S/N Ratio | 46dB or more (AGC OFF) |
| Scanning System | 2:1 interlace |
| Video Output | 1.0Vp-p (Sync. Negative) Termination 75Ω |
| Synchronization | Internal / External (Line-Lock) |
| Angle of View | 51.2 (Wide End), 5.58 (Tele End) |
| IR LEDs | 30 IR LEDs |
| On Screen Display Menu | Yes |
| Auto Gain Control | Yes |
| Digital Zoom | Yes |
