Ganz HSB-H37-4 1080p Height Strip IP Network Camera, 3.7mm Lens, Black Housing, POE

SKU
HSB-H37-4
Model No
HSB-H37-4
$1,125.00
Qty:
Product Highlights
    • Easy and Flexible Installation
    • Full HD 1080p @ 30fps
    • Image Rotation for vertically oriented space
    • 3.7mm Fixed Lens
    • Digital Day/Night and WDR

The Ganz IP height strip camera delivers 1080p resolution with SDXC Edge Recording and mounts discreetly to a doorframe. It’s designed to supplement standard surveillance cameras by capturing facial images and height.

CCTV Resolution Comparison

Features

  • Easy and Flexible Installation
  • Full HD 1080p @ 30fps
  • Image Rotation for vertically oriented space
  • 3.7mm Fixed Lens
  • Digital Day/Night and WDR
  • Imbedded Intelligence Technology providing intelligent analysis of video with application areas including intrusion detection, vehicle monitoring, people counting and loitering detection, camera tampering and failure detection
  • SDXC Edge Recording (up to 64GB)
  • Power over Ethernet (IEEE 802.3af)
  • ONVIF Compliant (Profile S)
SKU  HSB-H37-4
Features  Auto Gain Control, Automatic White Balance, Back Light Compensation, Day/Night, Digital Noise Reduction, Motion Detection Tracking, ONVIF, Wide Dynamic Range
Manufacturer  Ganz
Camera Signal     Network IP
Connection Type  Wired
Infrared Distance    Non Infrared
Resolution    1080p
Lens Type    Fixed
Lens Size    3.7mm
Mount Type  Ceiling
Compression Method    H.264, MPEG-4, M-JPEG
Durability    Indoor
Voltage  12vDC, PoE
Automatic Gain Control (AGC)    Auto
Dimensions (W x H)  1.7” W x 1.4” D x 34.1” H
Image Device    1/3” 1080p CMOS
Image Pixels-Effective1920 x 1080
Minimum Scene Illumination  Color: 1.4 lux / BW: 0.01 lux (DSS ON)
Operating Humidity    Humidity up to 90% RH (non-condensing)
Operating Temperature    0°C ~ 40°C (32°F ~ 122°F)
Power Consumption  3W @ 12VDC
Protocols  QoS Layer 3 DiffServ, TCP/IP, UDP/IP, HTTP, HTTPS, RTSP, RTCP, RTP/UDP, RTP/TCP, mDNS, UPnP™, SMTP, DHCP, DNS, DynDNS, NTP, SNMPv1/v2c/v3(MIBII), IGMP, ICMP, SSLv2/v3, TLSv1
Digital Noise Reduction    Supported
Motion Detection Tracking    Supported
Back Light Compensation  On (possible to designate zone) / Off
Automatic White Balance    ATW / Manual
Auto Gain Control    Yes
Day/Night    Yes
Digital Noise Reduction    Yes
Automatic White Balance    Yes
Back Light Compensation    Yes
Motion Detection Tracking    Yes
Wide Dynamic Range    Yes
ONVIF  Yes
There are no related videos.
Downloads & Manuals
SKU
HSB-H37-4
Availability: In stock
