ENS HNC3I889-M1PV-28-E2 8 Megapixel Network IP Outdoor IR Diamond IPC Mini Board Camera with 2.8mm Lens
SKU
HNC3I889-M1PV-28-E2
Model No
HNC3I889-M1PV-28-E2
$370.50
Product Highlights
- Housing: Panoramic
- Resolution: 4K / 8MP
- Lens Category: 2.8mm Fixed
- Night Vision: Full Time Color, Infrared / IR, LED
- WDR: True WDR
Speak to an expert
ENS Diamond is a cutting-edge AI series designed to enhance surveillance accuracy and efficiency. Utilizing independent AI chips and deep learning algorithms, it excels in identifying human and vehicle targets, allowing users to respond swiftly. The HNC3I889-M1PV-28-E2 model reduces bandwidth and storage requirements through advanced AI Coding technology and supports smart functions like perimeter protection and Smart Motion Detection (SMD). With Starlight technology and a large aperture lens, it also delivers exceptional image clarity in low-light conditions.
ENS Diamond HNC3I889-M1PV-28-E2 SMD 4.0
- Smart Motion Detection (SMD): Utilizes advanced algorithms to accurately detect and classify targets, minimizing false alarms by excluding non-target objects.
- Enhanced PTZ Tracking: EPTZ technology allows simultaneous zooming and tracking of multiple targets, providing comprehensive situational awareness.
- Siren and Light Active Deterrence: Offers integrated voice alarms and customizable light alerts to effectively deter intrusion events.
- Smart Dual Light Technology: Switches between IR and warm light to optimize image capture during the day and night while minimizing light pollution.
- One-tap Disarming: Simplifies control over alarms and event triggers through a user-friendly mobile app, catering to diverse operational scenarios.
- Robust Environmental Protection: IP67 rated, ensuring functionality in various outdoor conditions, resistant to dust and water ingress.
- Cyber Security Measures: Implements advanced security protocols to safeguard against cyber threats, ensuring the integrity of the device.
ENS Diamond HNC3I889-M1PV-28-E2 Detailed Specifications
| Outputs | 180° wide angle splicing image |
| Resolution | Max. 8 MP (4096 × 1860)@20 fps |
| Codec | H.265 codec, high compression rate, ultra-low bit rate |
| Illumination | Built-in IR LED (max. 25m) and warm light (max. 20m) |
| Coding Options | ROI, SMART H.264 +/H.265+, AI H.264/H.265 |
| Dynamic Range Features | WDR, 3D NR, HLC, BLC, digital watermarking |
| Audio/Alarm I/O | Alarm: 1 in, 1 out; audio: 1 in, 1 out |
| Storage | Supports max. 256 G Micro SD card |
| Power Supply | 12 VDC/PoE, easy installation |
| Protection Rating | IP67 rated |
| Alarm Features | Sound and light alarm (red and blue lights) |
| Tracking Technology | EPTZ: Enlarge and track intelligent alarm targets |
| Smart Detection | SMD 4.0 technology |
| Disarming Feature | One-tap arming/disarming via alarm input |
SKU  | HNC3I889-M1PV-28-E2 |
|---|---|
| Features | Audio, Auto Gain Control, Automatic White Balance, Back Light Compensation, Day/Night, Digital Noise Reduction, Motion Detection Tracking, ONVIF, Privacy Masking, Weather Resistant, Wide Dynamic Range, 4K Resolution |
| Manufacturer | ENS |
Camera Signal  | Network IP |
| Connection Type | Wired |
| Infrared Distance | 61~100 Feet |
| Resolution | 8 Megapixel |
| Lens Type | Fixed |
| Lens Size | 2.8mm |
| Mount Type | Ceiling, Wall |
| Compression Method | H.264B, H.264H, H.264, Smart H.265+, Smart H.264+, M-JPEG, H.265 |
| Durability | Weather Resistant |
| Voltage | 12vDC, PoE |
| Automatic Gain Control (AGC) | Auto |
| Dimensions (W x H) | Φ122 mm × 135.2 mm (Φ4.80" × 5.32" ) |
| Electronic Shutter | Auto/Manual 1/3 s–1/100,000 s |
| Image Device | Dual 1/2.7" CMOS |
| IR LEDs | 2 (IR LED) |
| Minimum Scene Illumination | 0.005 [email protected] (Color, 30 IRE) , 0.0005 [email protected] (B/W, 30 IRE) , 0 lux (Illuminator on) |
| Operating Humidity | ≤95% |
| Operating Temperature | -40 °C to +60 °C (–40 °F to +140 °F) |
| Power Consumption | Basic: 3.95 W (12 VDC); 4.95 W (PoE) , Max. (H.265+WDR+ warm light+siren and light active deterrence + intelligence on): 8.7 W (12 VDC); 10.85 W (PoE) |
| Protocols | IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP; P2P |
| S/N Ratio | >56 dB |
| Scanning System | Progressive |
| Weatherproof | IP67 |
| Digital Noise Reduction | 3D NR |
| Angle of View | Horizontal: 180°; Vertical: 86° |
| Rotation Angle | 0°–360° |
| Motion Detection Tracking | OFF/ON (4 areas, rectangular) |
| Back Light Compensation | Yes |
| Automatic White Balance | Auto; natural; street lamp; outdoor; manual; regional custom |
| IR Distance | Up to 25 m (82.02 ft) |
| Audio | Yes |
| Auto Gain Control | Yes |
| Day/Night | Yes |
| Digital Noise Reduction | Yes |
| Automatic White Balance | Yes |
| Back Light Compensation | Yes |
| Motion Detection Tracking | Yes |
| Privacy Masking | Yes |
| Wide Dynamic Range | Yes |
| ONVIF | Yes |
