Hanwha Vision HCP-6320HA 1080p Analog HD 32x PTZ Dome Camera, IP66, IK10
SKU
HCP-6320HA
Model No
HCP-6320HA
$903.89
Product Highlights
- Full HD (1920 x 1080, 30fps) resolution
- [email protected], B/W : [email protected]
- Powerful 32x zoom (4.44 ~ 142.6mm), Digital 16x
- Day & Night (ICR), Defog, WDR (120dB), SSNRIII
- Preset 700?/sec, Azimuth
Speak to an expert
1080p Analog HD 32x PTZ Dome Camera, IK10
- The HCP-6320A from Hanwha Vision is a high-performance 1080p analog HD 32x PTZ dome camera designed for robust surveillance needs. With advanced features like powerful zoom, exceptional low-light performance, and weather-resistant housing, this camera ensures reliable monitoring in various conditions.
Camera Functions
Auto Gain Control
Auto White Balance
BLC
Day/Night Vision
3D DNR
Digital Zoom
Flickerless
Mirror
Privacy Masking
Weather Resistant
WDR
Camera Features
| Full HD (1920 x 1080, 30fps) resolution | Preset 700/sec, Azimuth |
| [email protected], B/W: [email protected] | IK10 |
| Powerful 32x zoom (4.44 ~ 142.6mm), Digital 16x | RS-485, Coax control |
| Day & Night (ICR), Defog, WDR (120dB), SSNRIII |
Durable PTZ Cameras for Reliable Performance
PTZ (pan-tilt-zoom) cameras make it possible to monitor large areas with a single camera, offering both wide and close-up views for the details required. Our PTZ IP cameras are designed for both indoor and outdoor applications to work in all lighting and weather conditions.
Wide area coverage- Never miss a moment with 360-degree views and wide tilt range.
Integrated IR illumination- See up to 200m in the dark with integrated IR illumination.
Low latency - Track objects easily with low latency, smooth pan, tilt and zoom controls.
Additional Hanwha Vision Products
SKU  | HCP-6320HA |
|---|---|
| Features | Auto Gain Control, Automatic White Balance, Back Light Compensation, Day/Night, Digital Noise Reduction, Digital Zoom, Flickerless, Mirror, Privacy Masking, Weather Resistant, Wide Dynamic Range |
| Manufacturer | Hanwha Vision |
| NDAA | Compliant |
Camera Signal  | HD-AHD |
| Resolution | 1080p |
| Sensor Option | 1/2.8" CMOS |
| Lens Type | Motorized Zoom |
| Lens Size | 32X |
| Infrared Distance | Non Infrared |
| Durability | Weather Resistant |
| Mount Type | Pendant |
| Voltage | 24vAC |
| Electronic Shutter | Minimum / Maximum / Anti flicker (2 ~ 1/12,000sec) |
| Image Device | 1/2.8" 2.38M CMOS |
| Image Pixels Total | 1,952(H) x 1,116(V), 2.18M pixels |
| Image Pixels-Effective | 1,944(H) x 1,104(V), 2.14M pixels |
| Minimum Scene Illumination | Color : 0.3Lux (1/30sec, F1.6, 50IRE) , 0.005Lux (2sec, F1.6, 50IRE), B/W : 0.03Lux (1/30sec, F1.6, 50IRE), 0.0005Lux (2sec, F1.6, 50IRE), Color : 0.2Lux (1/30sec, F1.6, 30IRE), 0.003Lux (2sec, F1.6, 30IRE), B/W : 0.01Lux (1/30sec, F1.6, 30IRE), 0.0001Lux |
| Operating Humidity | Less than 90% RH |
| Operating Temperature | -50°C ~ +55°C (-58°F ~ +131°F) |
| Dimensions (W x H) | Ø220.0 x 293.6mm (Ø8.66" x 11.56") |
| Power Consumption | Max. 24W (Heater off),Max. 65W (Heater on) |
| Privacy Zone | Off / On (32 zones of rectangular zone) |
| Protocols | RS-485 : Samsung-T/E, Pelco-P/D, Sungjin, Panasonic, Honeywell, AD, Vicon, Bosch, GECoaxial : ACP (AHD Coax Protocol) |
| S/N Ratio | 50dB |
| Scanning System | Progressive |
| Signal System | PAL/NTSC |
| Video Output | AHD : 1080p, BNCCVBS : SD, DIP connector type |
| Weatherproof | IP66 |
| Digital Noise Reduction | SSNRIII (2D+3D noise filter) (Off / On) |
| Mirror | Off / On |
| Angle of View | H : 62.8Ëš(Wide) ~ 2.23Ëš(Tele) / V : 36.8Ëš(Wide) ~ 1.26Ëš(Tele) |
| Backlight Compensation | Off / BLC / HLC |
| Automatic White Balance | ATW / AWC / Manual / Indoor / Outdoor / Mercury / Sodium |
| Auto Gain Control | Off / Low / Middle / High |
| Motion Detection | Off / On (4ea rectangular zone) |
| Back Light Compensation | Yes |
| Automatic White Balance | Yes |
| Day/Night | Yes |
| Digital Noise Reduction | Yes |
| Mirror | Yes |
| Wide Dynamic Range | Yes |
| Privacy Masking | Yes |
| Auto Gain Control | Yes |
| Flickerless | Yes |
| Digital Zoom | Yes |
