CNB GSDCT-GN685 380 TVL Analog Indoor Box Camera, No Lens
SKU
GSDCT-GN685
Model No
GSDCT-GN685
$20.96
Product Highlights
- 380 TVL analog indoor box camera
- No lens
Speak to an expert
The GSDCT-GN685 from CNB is a 380 TVL analog indoor box camera, no lens. This model offers reliable surveillance capability with its compact design, making it perfect for indoor applications where quality video monitoring is needed.
CNB GSDCT-GN685 Camera Features
- Resolution: 380 TVL - Provides clear and detailed images for effective surveillance.
- Design: Indoor box camera - Compact and unobtrusive, suitable for various indoor settings.
- Analog Output: Easy integration - Compatible with existing analog CCTV systems for seamless setup.
- Lens Compatibility: Lens sold separately - Offers flexibility to choose the right lens for specific monitoring needs.
- Durability: Robust construction - Built to withstand daily use in a variety of environments.
Detailed Camera Specifications for CNB GSDCT-GN685
| Model | GSDCT-GN685 |
| Image Sensor | 380 TVL |
| Video Output | Analog |
| Lens Type Compatibility | No Lens Included |
| Dimensions | Compact Size |
| Weight | Lightweight |
SKU  | GSDCT-GN685 |
|---|---|
| Features | Auto Gain Control, Automatic White Balance, Back Light Compensation, Flickerless |
| Manufacturer | CNB |
Camera Signal  | Analog |
| Resolution | 380 TVL |
| Sensor Option | 1/3" CCD |
| Lens Type | Not Included |
| Infrared Distance | Non Infrared |
| Durability | Indoor |
| Mount Type | Bracket Required |
| Voltage | 12vDC, 24vAC |
| Electronic Shutter | NTSC: 1/60 ~ 1/100,000 ; PAL 1/50 ~ 1/100,000 |
| Image Device | 2:1 Interalce Transfer 1/3 Inch SUPER HAD CCD |
| Image Pixels-Effective | NTSC - 510(H) x 492(V) |
| Minimum Scene Illumination | 0.3Lux (F1.4, 30IRE, AGC On), 0.1Lux (F1.4, 30IRE, AGC On) |
| Operating Temperature | -10°C~+50°C (Recommendation: -5°C~+40°C) |
| Dimensions (W x H) | 124 x 62 x 57mm |
| Power Consumption | 2.8W (Max.) |
| S/N Ratio | More than 48dB (AGC Off) |
| Signal System | NTSC |
| Video Output | Composite: 1.0V p-p, 75Ω, Unbalanced |
| Synchronization | Internal |
| Backlight Compensation | On/Off Selectable |
| Automatic White Balance | AWB |
| Auto Gain Control | On / Off Selectable (28dB) |
| Flickerless | On/Off Selectable |
| Back Light Compensation | Yes |
| Automatic White Balance | Yes |
| Auto Gain Control | Yes |
| Flickerless | Yes |
