VIVOTEK's FE9391-EHV-v2 is an outdoor fisheye network camera, featuring a detailed 12-Megapixel sensor for superb image quality. It has WDR Pro to maintain optimal image quality in high contrast lighting environments as well as H.265 compression with Smart Stream III to reduce bandwidth and storage consumption to a minimum. Equipped with IR illuminators and VIVOTEK's Smart IR II technology, the FE9391-EHV-v2 can see up to 20m radius in total darkness. The housing is IP66-rated for protection from rain and dust, as well as IK10-rated for robust protection against acts of vandalism. With added NEMA 4X protection, even more extreme offshore applications will not be an issue. The 12-Megapixel fisheye lens provides a 360 degree surround view with no blind spots, excellent for coverage of open areas such as airports, schools, parking garages, and more. The FE9391-EHV-v2 comes fully equipped with VIVOTEK's Smart VCA (Video Content Analysis). With AI based deep-learning and Smart Motion Detection, Smart VCA will enable users to quickly and accurately detect event triggers such as intrusion detection and missing object alerts. This suite of analytic functions is only available on our SUPREME line of products.
VIVOTEK FE9391-EHV-v2 Camera Features
12-Megapixel CMOS Sensor - Delivers exceptional image clarity and detail for high-resolution monitoring.
30 fps @ 2944x2944 - Ensures smooth and fluid video capture for clear surveillance footage.
360° 20M IR with Smart IR II - Provides comprehensive nighttime visibility without blind spots up to 20 meters.
WDR Pro (120dB) - Enhances image quality in challenging lighting conditions, maintaining detail across bright and dark areas.
Smart Motion Detection - Reduces false alarms through intelligent analysis of video content.
Smart VCA - Equipped with advanced analytics like intrusion, crowd, and loitering detection for improved security management.
Trend Micro IoT Security - Offers enhanced protection against cybersecurity threats, ensuring the integrity of surveillance data.
Local Dewarp - Allows for real-time correction of fisheye distortion for accurate image representation.
Audio, Auto Gain Control, Automatic White Balance, Back Light Compensation, Day/Night, Digital Noise Reduction, Digital Zoom, Heater & Fan, Mirror, Motion Detection Tracking, ONVIF, Vandal Resistant, Weather Resistant, Wide Dynamic Range
Manufacturer
Vivotek
NDAA
Compliant
Camera Signal
Network IP
Connection Type
Wired
Infrared Distance
61~100 Feet
Resolution
12 Megapixel
Lens Type
Fixed
Lens Size
1.22mm
Mount Type
Ceiling, Wall
Compression Method
H.264, M-JPEG, H.265
Durability
Vandal Resistant, Weather Resistant
Voltage
PoE
Dimensions (W x H)
ø 150 x 68.2 mm
Electronic Shutter
1/5 sec. to 1/32,000 sec.
Image Device
1/2.3" Progressive CMOS
IR LEDs
4
Minimum Scene Illumination
0.1 lux @ F2.0 (Color) <0.005 lux @ F2.0 (B/W), 0 lux with IR illumination on
Operating Humidity
90% RH (non-condensing)
Operating Temperature
-40°C ~ 55°C (-40°F ~ 131°F) (IR of f ), -40°C ~ 50°C (-40°F ~ 122°F) (IR on)
FE9391-EHV-v2-Specsheet
