Pelco EVO-05LND 5 Megapixel Evolution Mini 180°-360° Outdoor Camera, No Lens, Black
SKU
EVO-05LND
Model No
EVO-05LND
$550.85
Product Highlights
- Constant 360° surveillance with no blind spots
- No moving parts, no maintenance and silent operation
- Up to 30 fps video stream at 1 MP and ¼ MP
- 0.2 lux minimum illumination and electronic WDR
- PoE powered
Speak to an expert
5 Megapixel Evolution Mini 180°-360° Outdoor Camera
- The EVO-05LND from Pelco is a 5 megapixel evolution mini 180°-360° outdoor camera, no lens, black.
Camera Functions
Audio
Auto Gain Control
Auto White Balance
Digital Zoom
Motion Detection
Onvif
Privacy Masking
Vandal Resistant
Weather Resistant
WDR
Camera Features
| Constant 360° surveillance with no blind spots | RJ45 connection available |
| No moving parts, no maintenance and silent operation | Market leading Oncam 3D dewarping software |
| Up to 30 fps video stream at 1 MP and ¼ MP | Full Live and retrospective dewarping available |
| 0.2 lux minimum illumination and electronic WDR | Camera features are accessible through VMS platforms |
| PoE powered | Simultaneous multiple video streams |
| microSD card slot for local event recording | 10x digital zoom capability through client-side dewarping |
| Configurable privacy regions | H.264 / MJPEG streaming with multiple quality levels |
| Polygonal Video Motion Detection regions | Optimizes bandwidth and storage utilization |
| Simple and easy installation | Intuitive web-based interface for viewing and configuration |
| IP66 rated enclosure for weather protection | Supported by major VMS / NVR systems including VideoXpert (version 1.6 or later) and Digital Sentry (version 7.8.90 or later) |
| IK10 rating for vandalism protection | ONVIF profile S conformant |
| EN50155 / EN45545 transport certification |
Introduction to Evolution 360 Degree IP Cameras
The Evolution range consists of a 5 megapixel camera and exciting features, including high frame rate, H.264, on-board SD card, supports POE, digital input and output and audio capabilities. Evolution also comes with a range of accessories including pole, pendant and wall mount. This new approach for 360-degree surveillance cameras greatly enhances the ease and speed of installation and does not limit the 360 to wall or ceiling mounts. A differentiating strength of the new Evolution range is its innovative modular design, capable of being mounted on a range of available housings to allow for indoor, outdoor, surface mount and concealed applications.
Additional Pelco Products
SKU  | EVO-05LND |
|---|---|
| Features | Audio, Auto Gain Control, Automatic White Balance, Digital Zoom, Motion Detection Tracking, ONVIF, Privacy Masking, Vandal Resistant, Weather Resistant, Wide Dynamic Range |
| Manufacturer | Pelco |
| NDAA | Compliant |
Camera Signal  | Network IP |
| Connection Type | Wired |
| Infrared Distance | Non Infrared |
| Resolution | 5 Megapixel |
| Lens Type | Not Included |
| Mount Type | Ceiling, Wall |
| Compression Method | H.264 |
| Durability | Vandal Resistant, Weather Resistant |
| Voltage | PoE |
| Dimensions (W x H) | 119 x 68 mm (4.7 x 2.7 in.) |
| Image Device | 1/2.5-inch Sony CMOS Sensor |
| Minimum Scene Illumination | 0.2 lux = 50 IRE F/2.0 (6500 K) |
| Operating Humidity | Up to 98% non-condensing |
| Operating Temperature | -40 to +55° C (-40 to +131° F) |
| Power Consumption | 4.13 W |
| Privacy Zone | 10 configurable privacy regions |
| Weatherproof | IP66 |
| Angle of View | 180º Horizontal, 168º Vertical |
| Motion Detection Tracking | 8 configurable regions |
| Automatic White Balance | Auto White Balance (Range = approximately 2500 K~8000 K) |
| Audio | Yes |
| Auto Gain Control | Yes |
| Automatic White Balance | Yes |
| Motion Detection Tracking | Yes |
| Privacy Masking | Yes |
| Wide Dynamic Range | Yes |
| ONVIF | Yes |
| Digital Zoom | Yes |
