Digital Watchdog DWC-MF5Wi8TW 5 Megapixel Network IR Outdoor Dome Camera with 8mm Lens
SKU
DWC-MF5Wi8TW
Model No
DWC-MF5Wi8TW
was $406.99 Special Price $342.02
Product Highlights
- 5MP 1/2.8″ image sensor at real-time 30fps
- Star-Light Plus™ color in near-total darkness technology
- Intelligent Video Analytics (IVA)
- Extended Intelligent Video Analytics (IVA+ required)
- Seamless integration and control of IVA rules with DW Spectrum® IPVMS
Speak to an expert
The Digital Watchdog DWC-MF5Wi8TW is a high-performance 5 Megapixel Network IR Outdoor Dome Camera designed for optimal security and surveillance. Equipped with an 8mm lens and advanced imaging technologies, this camera provides exceptional clarity day or night. Its durable construction and environmental ratings make it suitable for various outdoor applications, while features like Two Way Audio and Intelligent Video Analytics enhance its functionality and usability.
Digital Watchdog DWC-MF5Wi8TW Camera Features
- 5MP Image Sensor: Achieve stunning image quality at real-time 30fps for clear visuals.
- Star-Light Plus™ Technology: Capture color images in near-total darkness, ensuring detailed surveillance even at night.
- Intelligent Video Analytics: Enhance security monitoring by enabling improved event detection and reducing false alarms.
- True Wide Dynamic Range (WDR): Balance bright and dark areas in a scene, optimizing visibility in challenging lighting conditions.
- Triple Codecs: Supports H.265, H.264, and MJPEG, allowing for flexible streaming options and significant bandwidth savings.
- 50’ Smart IR™: Intelligent infrared technology ensures even illumination during the night, providing reliable nighttime visibility.
- Ultra Low-Profile Design: Discreet vandal dome structure allows for effective surveillance without drawing attention.
- Smart DNR™: 3D digital noise reduction improves image quality in low-light conditions by minimizing graininess.
- Two-Way Audio: Enables communication through the camera, adding an interactive element to surveillance.
- Environmentally Rated: IP66 dust-tight and water-resistant rating ensures durability in harsh weather conditions.
- IK10 Impact Resistance: Protects against vandalism, making it suitable for high-risk environments.
- Micro SD Card Slot: Facilitates local storage (card not included), allowing for easy access to recordings.
- Programmable Privacy Zones: Control areas of the camera view to maintain privacy and protect sensitive locations.
- PoE and DC12V Compatibility: Offers flexible power options for easy installation.
- NDAA Compliant: Meets the necessary compliance standards for government usage.
Digital Watchdog DWC-MF5Wi8TW Detailed Specifications
| Model | DWC-MF5Wi8TW |
| Megapixels | 5MP |
| Lens | 8mm |
| Image Sensor | 1/2.8” |
| Frame Rate | 30fps |
| IR Distance | 50ft |
| Environmental Rating | IP66 |
| Impact Resistance | IK10 |
| Audio | Two-Way Audio |
| Private Zones | Programmable |
| Connectivity | PoE and DC12V |
| Compliance | NDAA Compliant |
SKU  | DWC-MF5Wi8TW |
|---|---|
| Features | Audio, Auto Gain Control, Automatic White Balance, Day/Night, Digital Noise Reduction, Flickerless, Mirror, Motion Detection Tracking, ONVIF, Privacy Masking, Vandal Resistant, Weather Resistant, Wide Dynamic Range |
| Manufacturer | Digital Watchdog |
| NDAA | Compliant |
Camera Signal  | Network IP |
| Connection Type | Wired |
| Infrared Distance | 0~60 Feet |
| Resolution | 5 Megapixel |
| Lens Type | Fixed |
| Lens Size | 8mm |
| Mount Type | Ceiling, Wall |
| Compression Method | H.264, M-JPEG, H.265 |
| Durability | Vandal Resistant, Weather Resistant |
| Voltage | 12vDC, PoE |
| Automatic Gain Control (AGC) | Auto |
| Dimensions (W x H) | 4.9” x 2.9” (125 x 74.3 mm) |
| Electronic Shutter | 1/15 ~ 1/32000 |
| Image Device | 5MP 1/2.8“ CMOS |
| Image Pixels Total | 2592(H) X 1944(V) |
| Minimum Scene Illumination | 0.16 lux (color), 0.0 lux (B/W) |
| Operating Humidity | 10-90% (non-condensing) |
| Operating Temperature | -4°F ~ 122°F (-20°C ~ 50°C) |
| Power Consumption | DC12V: max 5.9W, PoE: max 7.2W |
| Privacy Zone | 16 programmable privacy masks |
| Protocols | TCP/IP, UDP, Auto IP, RTP (UDP/TCP), RTSP, NTP, HTTP, HTTPS, SSL, DNS, DDNS, DHCP, FTP, SMTP, ICMP, SNMPv1/ v2/v3 (MIB-2), ONVIF |
| Weatherproof | IP66 |
| Digital Noise Reduction | 3D |
| Angle of View | 37.8° / 22° |
| IR Distance | 15m/50ft |
| Audio | Yes |
| Auto Gain Control | Yes |
| Day/Night | Yes |
| Digital Noise Reduction | Yes |
| Automatic White Balance | Yes |
| Flickerless | Yes |
| Motion Detection Tracking | Yes |
| Privacy Masking | Yes |
| Wide Dynamic Range | Yes |
| Mirror | Yes |
| ONVIF | Yes |
