Digital Watchdog DWC-MF4Wi4WC5 4 Megapixel Network IR Outdoor Dome Camera with 4mm Lens
SKU
DWC-MF4Wi4WC5
Model No
DWC-MF4Wi4WC5
was $733.00 Special Price $559.09
Product Highlights
- All-in-one cameras, no server required
- 4MP 1/3″ image sensor at real-time 30fps
- 4.0mm fixed lens
- Built-in 512GB and 1TB storage options for up to 60 days of retained video*
- Easily to deploy with pre-loaded DW Spectrum IPVMS for out-of-the-box operation
Speak to an expert
The Digital Watchdog DWC-MF4Wi4WC5 is a high-performance 4 Megapixel Network IR Outdoor Dome Camera designed for both indoor and outdoor use. With its advanced imaging technology, built-in storage options, and robust environmental ratings, this camera ensures clear surveillance and effortless installation, making it a top choice for security needs.
Digital Watchdog DWC-MF4Wi4WC5 Key Features
- All-in-one cameras: No server required, simplifying installation and reducing overhead costs.
- 4MP 1/3” image sensor: Captures high-resolution video in real-time at 30fps for clear and detailed footage.
- 4.0mm fixed lens: Provides a wide viewing angle, ideal for monitoring large areas.
- Built-in storage: Options for 512GB and 1TB allow up to 60 days of video retention, ensuring you never miss important footage.
- Pre-loaded DW Spectrum IPVMS: Ensures out-of-the-box operation, making deployment quick and easy.
- 24/7 access: Live and recorded video feed is accessible anytime, offering peace of mind.
- Automatic installation: First power on activates installation and licensing to save time.
- Connect up to 30 cameras: Scalable solution for expanding surveillance with multiple MEGApix CaaS edge cameras.
- True Wide Dynamic Range (WDR): Enhances image quality in varying lighting conditions.
- Dual recording option: Integrates with Blackjack NAS appliance for additional storage flexibility.
- Dual codecs: Supports H.264 and MJPEG with simultaneous dual-stream for versatile streaming options.
- Smart IR™: Offers intelligent camera sync for optimal infrared illumination up to 50ft.
- Low-profile design: Outdoor vandal dome is unobtrusive and resistant to tampering.
- Smart DNR™: 3D digital noise reduction improves image clarity in low-light conditions.
- True day/night functionality: Features mechanical IR cut filter for optimal performance day and night.
- Programmable privacy zones: Allows for customized monitoring to protect sensitive areas.
- Auto gain control (AGC): Automatically adjusts for optimal image quality.
- Auto white balance (AWB): Ensures accurate color representation in all lighting conditions.
- Motion detection: Alerts you to movement, enhancing security monitoring.
- Built-in web server: Facilitates remote access and management of the camera settings.
- PoE class 3 and DC12V: Flexible power options simplify installation.
- Waterproof cabling: Ensures reliable performance in wet conditions.
- UL listed: Meets safety standards for reliable operation.
- ONVIF conformant: Profile S compliance ensures compatibility with various systems.
- NDAA compliant: Adheres to regulations ensuring secure and reliable surveillance solutions.
- IP66 rated: Certified as dust-tight and water-resistant, making it suitable for outdoor use.
- IK 10 rated: Impact-resistant casing protects against vandalism and physical damage.
Digital Watchdog DWC-MF4Wi4WC5 Detailed Specifications
| Feature | Details |
|---|---|
| Resolution | 4 Megapixel (2560x1440 @ 30fps) |
| Lens | 4.0mm fixed lens |
| Sensor Type | 1/3" CMOS Sensor |
| Storage Options | 512GB and 1TB built-in options |
| Infrared Range | 50ft Smart IR™ |
| Environmental Rating | IP66 dust-tight and water-resistant |
| Impact Resistance | IK 10-rated |
| Power Options | PoE class 3 and DC12V |
| Warranty | 5 Year Warranty |
SKU  | DWC-MF4Wi4WC5 |
|---|---|
| Features | Auto Gain Control, Automatic White Balance, Day/Night, Digital Noise Reduction, Flickerless, Motion Detection Tracking, ONVIF, Privacy Masking, Vandal Resistant, Weather Resistant, Wide Dynamic Range |
| Manufacturer | Digital Watchdog |
| NDAA | Compliant |
Camera Signal  | Network IP |
| Connection Type | Wired |
| Infrared Distance | 0~60 Feet |
| Resolution | 4 Megapixel |
| Lens Type | Fixed |
| Lens Size | 4mm |
| Mount Type | Ceiling, Wall |
| Compression Method | H.264, M-JPEG |
| Durability | Vandal Resistant, Weather Resistant |
| Voltage | 12vDC, PoE |
| Automatic Gain Control (AGC) | Auto |
| Dimensions (W x H) | 4.9" x 2.9" (125 x 74.3 mm) |
| Electronic Shutter | 1/30~1/32000 |
| Image Device | 4MP 1/3” CMOS |
| Image Pixels Total | 2688(H) x 1520(V) |
| Minimum Scene Illumination | 0.41 lux (color), 0.0 lux (B/W) |
| Operating Humidity | 10–90% RH (non–condensing) |
| Operating Temperature | -4°F ~ 122°F (-20°C ~ 50°C) |
| Power Consumption | DC12V: Max 5.6W, PoE: Max 7.4W |
| Privacy Zone | 16 programmable privacy masks |
| Protocols | Zero config(Auto IP), ONVIF, TCP/IP, UDP, RTP(UDP/TCP), RTSP, NTP, HTTP,HTTPS, SSL, DNS, DDNS, DHCP, FTP, SMTP, ICMP, SNMPv1/v2c/v3(MIB-2) |
| Weatherproof | IP66 |
| Digital Noise Reduction | 3D |
| Angle of View | 81° |
| IR Distance | 15m/50ft |
| Auto Gain Control | Yes |
| Day/Night | Yes |
| Digital Noise Reduction | Yes |
| Automatic White Balance | Yes |
| Flickerless | Yes |
| Motion Detection Tracking | Yes |
| Privacy Masking | Yes |
| Wide Dynamic Range | Yes |
| ONVIF | Yes |
