Hikvision DS-2CD6D54G1-IZS 20 Megapixel Outdoor Multi-Sensor PanoVu EXIR Flexible Network Camera, 2.8-12mm Lens
- 1/2.7" Progressive Scan CMOS
- 2560 x 1920 @ 24 fps
- Four Flexible Lenses
- FOV: Horizontal 100° to 49°, Vertical 72° to 36.4°, Diagonal 134.4° to 61.4°
- H.265+, H.265, H.264+, H.264
20 Megapixel Outdoor Multi-Sensor PanoVu EXIR Flexible Network Camera
- The DS-2CD6D54G1-IZS from Hikvision is a 20 Megapixel Outdoor Multi-Sensor PanoVu EXIR Flexible Network Camera, 2.8-12mm Lens. Hikvision's DS-2CD6D54G1-IZS EXIR PanoVu Flexible Outdoor Network Camera features 1/2.7" progressive scan CMOS sensors and four lenses. Each lens supports a resolution of up to 2560 x 1920 at 24 fps. Compression up to H.265+ saves bandwidth and storage space. EXIR technology extends the IR range to 100 feet (30 meters).
Camera Functions
Audio
Auto Gain Control
Auto White Balance
BLC
Day/Night Vision
3D DNR
Flickerless
Mirror
Motion Detection
Onvif
Privacy Masking
Vandal Resistant
Weather Resistant
WDR
Camera Features
| 1/2.7" Progressive Scan CMOS | 120 dB WDR |
| 2560 x 1920 @ 24 fps | 6 Behavior Analyses, 4 Exception Detections, and Face Detection |
| Four Flexible Lenses | 100 ft (30 m) IR Range |
| FOV: Horizontal 100° to 49°, Vertical 72° to 36.4°, Diagonal 134.4° to 61.4° | IP67, IK10 |
| H.265+, H.265, H.264+, H.264 | 4 x 2-Axis Individual Camera Gimbals |
PanoVu Series Network Camera
When designing surveillance applications, more and greater requirements have become necessary for monitoring
large areas such as public plazas, arenas, airports, busy traffic intersections, and the like. In very large settings,
security personnel need to see more with just one camera – not just a panoramic image, but zoomed-in, detailed
views as well.
With that in mind, Hikvision designed the PanoVu Series all-in-one cameras to capture both excellent panorama
and close-up details. Panoramic images are captured with four or eight 2-Megapixel sensors, rendering 180° or 360°
panoramic monitoring with real-time ultra-HD resolution. The integrated design and high-speed pan-tilt-zoom action
grants the user swift positioning over expansive areas with the power to bring sharp details into focus. At the same
time, the PanoVu Series Cameras utilize Hikvision’s ultra-low light Darkfighter technology, making colored images
possible in poorly lit environments.
View from Anywhere with Hik-Connect
Upgrade Your Experience with Hik Connect 5.0
Find all new upgrades, customize control of your devices, access to useful content, and enjoy better UI experience with Hik-Connect 5.0.
Additional Hikvision Products
SKU  | DS-2CD6D54G1-IZS |
|---|---|
| Features | Audio, Auto Gain Control, Automatic White Balance, Back Light Compensation, Day/Night, Digital Noise Reduction, Flickerless, Mirror, Motion Detection Tracking, ONVIF, Privacy Masking, Vandal Resistant, Weather Resistant, Wide Dynamic Range |
| Manufacturer | Hikvision |
Camera Signal  | Network IP |
| Connection Type | Wired |
| Infrared Distance | 61~100 Feet |
| Resolution | 20 Megapixel |
| Lens Type | Varifocal |
| Lens Size | 2.8-12mm |
| Mount Type | Ceiling, Wall |
| Compression Method | H.264, M-JPEG, H.265, H.264+, H.265+ |
| Durability | Vandal Resistant, Weather Resistant |
| Voltage | 12vDC, 24vAC, PoE |
| Dimensions (W x H) | Ø9.8" × 4.4" (Ø250 mm × 113 mm) |
| Electronic Shutter | 1 s to 1/100,000 s |
| Image Device | 1/2.7" progressive scan CMOS |
| IR Wavelength | 850 nm |
| Minimum Scene Illumination | Color: 0.0125 lux @ (Æ’/1.9, AGC on), B/W: 0.0025 lux @ (Æ’/1.9, AGC on) |
| Operating Humidity | 95% or less (non-condensing) |
| Operating Temperature | -22° to 140° F (-30° to 60° C) |
| Power Consumption | 12 VDC: 22 W; 24 VAC: 22 W; PoE: 19 W |
| Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1x, QoS, IPv6, UDP, Bonjour |
| Scanning System | Progressive |
| Weatherproof | IP67 |
| Digital Noise Reduction | 3D DNR |
| Angle of View | Horizontal field of view: 100° to 49°, Vertical field of view: 72° to 36.4°, Diagonal field of view: 134.4° to 61.4° |
| IR Distance | 30m/100ft |
| Audio | Yes |
| Auto Gain Control | Yes |
| Day/Night | Yes |
| Digital Noise Reduction | Yes |
| Automatic White Balance | Yes |
| Back Light Compensation | Yes |
| Flickerless | Yes |
| Motion Detection Tracking | Yes |
| On Screen Display Menu | Yes |
| Privacy Masking | Yes |
| Wide Dynamic Range | Yes |
| Mirror | Yes |
| ONVIF | Yes |
