Arecont Vision DC-V4212XJ4.3 2 Megapixel Modular Network Covert Camera with 4.3mm Lens
SKU
DC-V4212XJ4-3
Model No
DC-V4212XJ4-3
$346.00
Product Highlights
- Easy installation with DirectIP NVR
- Full HD (1080p) resolution
- Fixed-focal lens (f=4.3mm)
- micro SD/SDHC/SDXC
- Two-way audio
Speak to an expert
The DC-V4212XJ4.3 from Arecont Vision is a cutting-edge 2 megapixel Modular Covert Camera designed for seamless integration into any surveillance setup. Featuring H.265 compression at 30IPS, a compact 4.3mm lens, and comprehensive connectivity options like DirectIP 2.0 and ONVIF support, this camera ensures high-quality video performance while offering ease of installation and advanced features for efficient monitoring.
Arecont Vision DC-V4212XJ4.3 Camera Features
- Easy installation with DirectIP NVR: Simplifies setup by allowing direct connection to the NVR for quick configuration.
- Full HD (1080p) resolution: Provides crisp and clear images for effective monitoring and identification.
- Fixed-focal lens (f=4.3mm): Optimizes focal length for versatile surveillance applications.
- micro SD/SDHC/SDXC compatibility: Supports local storage options up to 512GB, ensuring reliable data retention.
- Two-way audio: Facilitates communication through the camera, enhancing security measures.
- Alarm in / out functionality: Integrates with external security systems for improved incident response capabilities.
- PoE (IEEE 802.3af Class 4): Allows power over Ethernet, reducing cable clutter and installation complexity.
- True wide dynamic range (WDR): Ensures clear images in varied lighting conditions, making it ideal for challenging environments.
- Supports ONVIF: Ensures compatibility with a wide range of third-party surveillance systems.
Detailed Camera Specifications - Arecont Vision DC-V4212XJ4.3
| Camera Type | Modular Covert Camera |
| Megapixels | 2 Megapixel |
| Lens | 4.3mm Fixed-focal |
| Image Sensor | 1/2.8" CMOS |
| Video Compression | H.265@30IPS |
| DirectIP Support | Yes |
| ONVIF Compliance | Yes |
| Audio | Two-way audio support |
| Alarm I/O | Yes |
| Storage | micro SD/SDHC/SDXC (Up to 512GB) |
| Power | 12V=, 0.42A, 5.04W, PoE IEEE 802.3at(Class 4), 6.3W |
| Dimensions | Compact design for covert applications |
SKU  | DC-V4212XJ4-3 |
|---|---|
| Features | Audio, Auto Gain Control, Back Light Compensation, Day/Night, Digital Noise Reduction, Mirror, Motion Detection Tracking, ONVIF, Privacy Masking, Wide Dynamic Range |
| Manufacturer | Arecont Vision |
| Connection Type | Wired |
Resolution  | 2 Megapixel |
| Lens Type | Fixed |
| Lens Size | 4.3mm |
| Compression Method | H.264, M-JPEG, H.265 |
| Voltage | 12vDC, PoE |
| Electronic Shutter | Auto / Manual (1/30,1/25Sec ~ 1/30000Sec) / Anti-Flicker |
| Image Device | 1/2.8" CMOS Progressive Sensor |
| Minimum Scene Illumination | COLOR : 0.0001 lux @ F2.0, B/W : 0.01 lux @ F2.0 |
| Operating Humidity | 0% ~ 90% |
| Operating Temperature | -10°C ~ +50°C (+14°F ~ +122°F) |
| Power Consumption | Max 6.3W, Max 5.04W |
| Privacy Zone | 8 Zones |
| Protocols | DirectIP 2.0 Protocol, IPv4, RTP/RTSP/TCP, RTP/RTSP/HTTP/TCP, RTP/UDP RTSP/TCP, HTTP, HTTPS, FTP, SNTP, SMTP, FEN, mDNS, Upnp |
| Angle of View | 81.6º(H), 42.3º(V), 99º(D) |
| Back Light Compensation | BLC, WDR, HLC |
| Audio | Yes |
| Auto Gain Control | Yes |
| Day/Night | Yes |
| Digital Noise Reduction | Yes |
| Back Light Compensation | Yes |
| Motion Detection Tracking | Yes |
| Privacy Masking | Yes |
| Wide Dynamic Range | Yes |
| Mirror | Yes |
| ONVIF | Yes |
