Arecont Vision DC-V4212XJ2.4 1920 x 1080 Full HD Covert Modular Camera with 2.4mm Lens
SKU
DC-V4212XJ2-4
Model No
DC-V4212XJ2-4
$346.00
Product Highlights
- Easy installation with DirectIP NVR
- Full HD (1080p) resolution
- Fixed-focal Board Type lens(f=2.4 mm)
- Micro SD/SDHC/SDXC
- Two-way audio
Speak to an expert
The Arecont Vision DC-V4212XJ2.4 is a high-performance covert modular camera designed for versatile surveillance needs. With its 1920 x 1080 Full HD resolution, easy integration with DirectIP NVR, and enhanced features like two-way audio and PoE support, this camera provides exceptional clarity and convenience for any deployment.
Arecont Vision DC-V4212XJ2.4 Camera Features
- Easy installation: Simplifies setup with DirectIP NVR support, allowing for quick deployment in various locations.
- Full HD resolution: Captures crisp, clear footage at 1080p, ensuring detailed surveillance.
- Fixed-focal Board Type lens: The 2.4 mm lens provides a wide field of view for comprehensive monitoring.
- Micro SD/SDHC/SDXC support: Offers local storage options up to 512GB for flexible data management.
- Two-way audio: Enables effective communication through the camera, enhancing security operations.
- Alarm in / out: Integrates with external alarm systems for improved monitoring and response.
- Power over Ethernet (PoE): Complies with IEEE 802.3at class 4, eliminating the need for separate power sources.
- True Wide Dynamic Range (WDR): Ensures clear images in challenging lighting conditions, improving overall visibility.
- ONVIF support: Ensures compatibility with a wide range of CCTV products for seamless integration.
- NDAA Compliant: Adheres to federal regulations, ensuring reliability in sensitive installations.
Arecont Vision DC-V4212XJ2.4 Detailed Specifications
| Sensor Type | 1/2.8" CMOS |
| Image Resolution | 1920 x 1080 (Full HD) |
| Frame Rate | H.265@30IPS |
| Lens Type | Fixed-focal Board Type (2.4 mm) |
| Audio Support | Two-way audio (in/out) |
| Storage Support | Micro SD/SDHC/SDXC (Up to 512GB) |
| Power Supply | 12V DC, 0.42A, 5.04W, PoE IEEE 802.3at (Class 4), 6.3W |
| Dynamic Range | True Wide Dynamic Range (WDR) |
| Compatibility | ONVIF compliant |
| Compliance | NDAA Compliant |
SKU  | DC-V4212XJ2-4 |
|---|---|
| Features | Audio, Auto Gain Control, Back Light Compensation, Day/Night, Digital Noise Reduction, Mirror, Motion Detection Tracking, ONVIF, Privacy Masking, Wide Dynamic Range |
| Manufacturer | Arecont Vision |
| Connection Type | Wired |
Infrared Distance  | 61~100 Feet |
| Resolution | 2 Megapixel |
| Lens Type | Fixed |
| Lens Size | 2.4mm |
| Compression Method | H.264, M-JPEG, H.265 |
| Voltage | 12vDC, PoE |
| Dimensions (W x H) | 153mm x 36.5mm x 132.7mm (6.02″ x 1.44″ x 5.22″) |
| Minimum Scene Illumination | Color : 0.1 lux, B/W : 0.01 lux |
| Operating Humidity | 0% ~ 90% |
| Operating Temperature | -10°C ~ +50°C (14°F ~ +122°F) |
| Power Consumption | Max 6.3W |
| Privacy Zone | 8 Zones |
| Protocols | DirectIP 2.0 Protocol, IPv4, RTP/RTSP/TCP, RTP/RTSP/HTTP/TCP, RTP/UDP RTSP/TCP, HTTP, HTTPS, FTP, SNTP, SMTP, FEN, mDNS, uPNP |
| Angle of View | 132.5º(H), 72.7º(V), 154.7º(D) |
| Back Light Compensation | OFF / BLC / HLC / WDR |
| IR Distance | 30m/98ft |
| Audio | Yes |
| Auto Gain Control | Yes |
| Day/Night | Yes |
| Digital Noise Reduction | Yes |
| Back Light Compensation | Yes |
| Motion Detection Tracking | Yes |
| Privacy Masking | Yes |
| Wide Dynamic Range | Yes |
| Mirror | Yes |
| ONVIF | Yes |
