Arecont Vision DC-D4517RX4.3 5 Megapixel Network Dome Camera with 4.3mm Lens
SKU
DC-D4517RX4-3
Model No
DC-D4517RX4-3
$185.33
Product Highlights
- Easy installation with DirectIP NVR
- H.265 and Intelligent Codec
- Affodable 5MP High Resolution
- PoE (IEEE 802.3af Class 3)
- IR LED (20m / 65.6ft (2 ea))
Speak to an expert
The DC-D4517RX4.3 from Arecont Vision is a high-performance 5 megapixel IR dome camera designed for indoor surveillance. With features like H.265 compression, PoE support, and a 4.3mm fixed lens, it ensures clear and efficient monitoring. The camera's advanced capabilities such as True Wide Dynamic Range (WDR) and infrared illumination up to 20 meters provide exceptional visibility in various lighting conditions, making it an ideal choice for comprehensive security applications.
Arecont Vision DC-D4517RX4.3 Camera Features
- Easy installation: Integrates seamlessly with DirectIP NVR for straightforward setup.
- H.265 and Intelligent Codec: Reduces bandwidth usage while maintaining high image quality.
- Affordable 5MP High Resolution: Captures detailed images for enhanced identification and monitoring.
- PoE (IEEE 802.3af Class 3): Simplifies power management through Ethernet cabling.
- IR LED (20m / 65.6ft): Ensures clear night-time visibility with infrared capability.
- Fixed-focal lens: Provides stable and clear images without distortion.
- True Wide Dynamic Range (WDR): Enhances visibility in high-contrast lighting situations.
- Day and night (ICR): Switches automatically for optimum performance in varying light conditions.
- Supports ONVIF: Compatible with various third-party systems for flexible integration.
Detailed Camera Specifications for Arecont Vision DC-D4517RX4.3
| Model | Areetcont Vision DC-D4517RX4.3 |
| Megapixels | 5MP |
| Lens | 4.3mm Fixed |
| Sensor Type | 1/2.8" CMOS |
| Compression | H.265@30ips |
| IR Distance | 20m / 65.6ft |
| Power Supply | PoE, IEEE 802.3af (Class 3), 7.5W |
| Dynamic Range | True WDR |
| Compatibility | ONVIF |
SKU  | DC-D4517RX4-3 |
|---|---|
| Features | Audio, Auto Gain Control, Automatic White Balance, Back Light Compensation, Day/Night, Mirror, Motion Detection Tracking, ONVIF, Privacy Masking, Wide Dynamic Range |
| Manufacturer | Arecont Vision |
| Connection Type | Wired |
Infrared Distance  | 61~100 Feet |
| Resolution | 5 Megapixel |
| Lens Type | Fixed |
| Lens Size | 4.3mm |
| Mount Type | Wall |
| Compression Method | H.264, M-JPEG, H.265 |
| Voltage | PoE |
| Dimensions (W x H) | Ø110 x 88mm(Ø4.33” x 3.46”) |
| Electronic Shutter | Auto / Manual (1/30 ~ 1/10,000), Anti-Flicker, Slow Shutter (1/7.5, 1/15) |
| Image Device | 1/2.8" CMOS Progressive Scan |
| Minimum Scene Illumination | COLOR : 0.15 lux @ F1.6 - TBD B/W : 0 lux (IR LED ON) - TBD |
| Operating Humidity | 0% ~ 90% |
| Operating Temperature | -10°C ~ +50°C (+14°F ~ +122°F) |
| Power Consumption | Max 7.5W |
| Privacy Zone | 8 Zones |
| Protocols | DirectIP 2.0 Protocol, IPv4, IPv6, RTP/RTSP/TCP, RTP/RTSP/HTTP/TCP, RTP/UDP RTSP/TCP, HTTP, HTTPS, FTP, SNTP, SMTP, FEN, mDNS, uPNP, SNMPv2 |
| Mirror | Horizontal / Vertical / Pivot |
| Angle of View | 4:3 mode : 80º(H) 56.7º(V) 106.9º(D) 16:9 mode : 80º(H) 41.1º(V) 95.4º(D) |
| Rotation Angle | -109° ~ 109° |
| Back Light Compensation | BLC |
| IR Distance | 20m/65ft |
| Audio | Yes |
| Auto Gain Control | Yes |
| Day/Night | Yes |
| Automatic White Balance | Yes |
| Back Light Compensation | Yes |
| Motion Detection Tracking | Yes |
| Privacy Masking | Yes |
| Wide Dynamic Range | Yes |
| Mirror | Yes |
| ONVIF | Yes |
