Arecont Vision DC-D4236RX-W 2 Megapixel Network Dome Camera with 2.8-12mm Lens
SKU
DC-D4236RX-W
Model No
DC-D4236RX-W
$366.00
Product Highlights
- Easy installation with DirectIP NVR
- Full HD (1080p) resolution
- Motorized Vari-focal lens (f=2.8 - 12mm)
- micro SD/SDHC/SDXC
- Two-way audio
Speak to an expert
The DC-D4236RX-W from Arecont Vision is a powerful 2 megapixel IR dome camera designed for indoor use, featuring advanced capabilities such as H.265 compression at 30 frames per second, a versatile 2.8-12mm motorized vari-focal lens, and enhanced connectivity options. With its robust performance and easy installation, this camera is perfect for comprehensive surveillance solutions.
Arecont Vision DC-D4236RX-W Camera Features
- Easy installation: Seamless integration with DirectIP NVR simplifies setup and management.
- Full HD resolution: Enjoy crisp, clear images with 1080p resolution for detailed monitoring.
- Motorized Vari-focal lens: Adjustable focal length (2.8 - 12mm) allows flexibility in viewing angles and distances.
- Micro SD storage: Supports up to 512GB storage for local video recording and easy retrieval.
- Two-way audio: Intercom functionality enables effective communication through the camera.
- Alarm in/out options: Provides enhanced security through integrated alarm features.
- Power over Ethernet (PoE): Simplifies installation with a single cable for both power and data.
- Day and night functionality: Infrared cut filter ensures optimal performance in varying light conditions.
- True wide dynamic range (WDR): Captures details in both bright and dark areas of the scene.
- IR LED range: Night vision capabilities up to 30m / 98.4 ft for effective surveillance in low-light environments.
Detailed Specifications for Arecont Vision DC-D4236RX-W
| Camera Type | 2 Megapixel IR Dome Camera |
| Lens | 2.8 - 12mm Motorized Vari-focal Lens |
| Video Compression | H.265 at 30ips |
| Image Sensor | 1/2.8" CMOS |
| Storage Support | Micro SD/SDHC/SDXC (Up to 512GB) |
| Power Supply | 12V=, 0.64A, 7.7W, PoE IEEE 802.3af (Class 3) |
| Alarm Features | Alarm in/out |
| Audio Features | Audio in/out |
| IR Range | 30m / 98.4 ft (6ea) |
| Base Color | White |
SKU  | DC-D4236RX-W |
|---|---|
| Features | Audio, Auto Gain Control, Automatic White Balance, Back Light Compensation, Day/Night, Mirror, Motion Detection Tracking, ONVIF, Privacy Masking, Wide Dynamic Range |
| Manufacturer | Arecont Vision |
| Connection Type | Wired |
Infrared Distance  | 61~100 Feet |
| Resolution | 2 Megapixel |
| Lens Type | Varifocal |
| Lens Size | 2.8-12mm |
| Mount Type | Ceiling, Wall |
| Compression Method | H.264, M-JPEG, H.265 |
| Voltage | PoE |
| Dimensions (W x H) | Ø122 x 103.4mm (Ø4.8" x 4.07") |
| Electronic Shutter | Auto / Manual (1/30 ~ 1/10,000), Anti-Flicker, Slow Shutter (1/7.5, 1/15) |
| Image Device | 1/2.8" CMOS Progressive Scan |
| Minimum Scene Illumination | COLOR : 0.0001 lux @ F1.4 B/W : 0 lux (IR LED ON) |
| Operating Humidity | 0% ~ 90% |
| Operating Temperature | -10°C ~ +50°C (+14°F ~ +122°F) |
| Power Consumption | Max 7.6W |
| Privacy Zone | 8 Zones |
| Protocols | DirectIP 2.0 Protocol, IPv4, IPv6, RTP/RTSP/TCP, RTP/RTSP/HTTP/TCP, RTP/UDP RTSP/TCP, HTTP, HTTPS, FTP, SNTP, SMTP, FEN, mDNS, uPNP, SNMPv2 |
| Mirror | Horizontal / Vertical / Pivot |
| Angle of View | Wide : 98º(H), 51º(V), 116º(D) Tele : 33º(H), 19º(V), 38º(D) |
| Rotation Angle | -177° ~ 177° |
| Back Light Compensation | BLC |
| IR Distance | 30m/98ft |
| Audio | Yes |
| Auto Gain Control | Yes |
| Day/Night | Yes |
| Automatic White Balance | Yes |
| Back Light Compensation | Yes |
| Motion Detection Tracking | Yes |
| Privacy Masking | Yes |
| Wide Dynamic Range | Yes |
| Mirror | Yes |
| ONVIF | Yes |
