CHeKT CKIPAi5MP-DL-TH-FR 640 X 480 Network IR Outdoor Dual Thermal Imaging Camera with 4.0mm Lens
SKU
CH-CKIPAi5MP-DL-TH-FR
Model No
CKIPAi5MP-DL-TH-FR
$1,499.00
Product Highlights
- HD (Human Detection) - ~ 35m (115 feet)
- Thermal (Human Detection) - ~60m (200 feet)
- Visible : 5MP Thermal : 640 x 480 Upscale
- H.265, H.264 and MJPEG compression
- Embedded AI Chip Technology for Video Analytics
Speak to an expert
The CHeKT CKIPAi5MP-DL-TH-FR is a state-of-the-art IP camera combining both HD and Thermal technology for unmatched surveillance capabilities. It is equipped with a deep learning AI chipset that intelligently switches between HD and Thermal modes, providing optimal performance in both day and night conditions. This versatile camera not only offers high-quality image resolution but also advanced detection methods for enhanced security.
CHeKT CKIPAi5MP-DL-TH-FR Camera Features
- HD (Human Detection): Detects human presence up to ~35m (115 feet) during the day with high clarity.
- Thermal (Human Detection): Extends detection range up to ~60m (200 feet) at night, utilizing thermal imaging technology.
- Visible & Thermal Resolution: 5MP for visible and 640 x 480 upscaled for thermal images, ensuring precise identification.
- Video Compression: Supports H.265, H.264, and MJPEG, maximizing storage efficiency and streaming quality.
- Embedded AI Technology: Enables sophisticated video analytics for real-time monitoring and response.
- Deep Learning Capabilities: Features object and people tracking for accurate surveillance.
- SMART Bitrate Control: Optimizes video quality based on network conditions, improving resource management.
- Power over Ethernet: Complies with IEEE 802.3af standards, simplifying installation with a single cable.
CHeKT CKIPAi5MP-DL-TH-FR Specifications
| Camera Type | HD and Thermal IP Camera |
| HD Detection Range | ~35m (115 feet) |
| Thermal Detection Range | ~60m (200 feet) |
| Visible Resolution | 5MP |
| Thermal Resolution | 640 x 480 (Upscaled) |
| Video Compression Formats | H.265, H.264, MJPEG |
| AI Capabilities | Embedded AI Chip for Video Analytics |
| Tracking Features | Deep Learning Object and People Tracker |
| Bitrate Control | SMART Bitrate Control |
| Power Supply | Power over Ethernet (IEEE 802.3af) |
SKU  | CH-CKIPAi5MP-DL-TH-FR |
|---|---|
| Features | Audio, Auto Gain Control, AI Analytics, Automatic White Balance, Day/Night, Digital Noise Reduction, Mirror, Motion Detection Tracking, ONVIF, Privacy Masking, Vandal Resistant, Weather Resistant, Wide Dynamic Range |
| Manufacturer | CHeKT |
Camera Signal  | Network IP |
| Connection Type | Wired |
| Resolution | 640 X 480 |
| Lens Type | Fixed |
| Lens Size | 4mm |
| Mount Type | Ceiling, Wall |
| Compression Method | H.264, M-JPEG, H.265 |
| Durability | Vandal Resistant, Weather Resistant |
| Voltage | 12vDC, PoE |
| Dimensions (W x H) | 106mrn(W) x 96.7mrn(H) x 216mm(D) |
| Image Device | Uncooled Vanadium Oxide Microbolometer |
| Operating Humidity | 10 - 90% RH (non-condensing) |
| Operating Temperature | [PoE] -30°C - 50°C ( -22°F - 122°F) [DC12V] -40°C - 50°C ( -40°F - 122°F ) |
| Power Consumption | DC12V Max 23.3W, PoE Max 11.5W |
| Protocols | TCP/IP, UDP, AutolP, RTP(UDP/TCP), RTSP, NTP, HTTP, HTTPS, SSL, DNS, DDNS, DHCP, FTP, SMTP, ICMP, SNMPv1/v2/v3(MIB -2), ONVIF |
| Weatherproof | IP67, IK09 |
| Digital Noise Reduction | 3D-DNR |
| Angle of View | Horizontal: Approx. 56°, Vertical: Approx. 42° |
| Audio | Yes |
| Auto Gain Control | Yes |
| Day/Night | Yes |
| Digital Noise Reduction | Yes |
| Automatic White Balance | Yes |
| Motion Detection Tracking | Yes |
| Privacy Masking | Yes |
| Wide Dynamic Range | Yes |
| Mirror | Yes |
| ONVIF | Yes |
