Avycon AVC-NCB51M 5 Megapixel H.265 Outdoor Network IR Bullet Camera with 2.8-12mm Lens
SKU
AVC-NCB51M
Model No
AVC-NCB51M
$990.00
Product Highlights
- 5MP ( 2880 x 1620 ) @ 30fps
- Max. Resolution: 2880 x 1620
- Supports Smart H.265/H.264 Encoding
- True Day & Night ICR
- Up to 114 ft. IR Illumination
Speak to an expert
The AVYCON AVC-NCB51M camera is a powerful 5MP H.265 Motorized Lens Bullet Camera, designed for outdoor surveillance. With True Day and Night mode capability, it ensures high-quality video capture even in low-light conditions, supported by up to 114ft of Smart IR Illumination. Its unique InfiniteColor technology enables color video in complete darkness using a white floodlight, making it a versatile choice for security needs. This camera also features a motorized 2.8-12mm lens for flexible focal length options and advanced video features like Digital NR, ROI, HLC, True WDR, and BLC.
AVYCON AVC-NCB51M Camera Features
- 5MP Resolution: Captures images at 2880 x 1620, ensuring clear and detailed footage.
- Smart H.265/H.264 Encoding: Reduces bandwidth usage and storage requirements, enhancing efficiency.
- True Day & Night ICR: Automatically switches to the appropriate mode based on lighting, providing optimal video quality at all times.
- Smart IR Illumination: Offers illumination up to 114ft, ensuring visibility in dark environments.
- Motorized 2.8-12mm Lens: Allows remote adjustments of focal length for customizable field of view.
- Advanced Video Features: Includes 3D DNR, True WDR, HLC, BLC, and ROI Encoding for superior video quality.
- Dual-Stream Support: Enables efficient streaming to different devices simultaneously.
- Remote Access: Compatible with Windows, macOS, iOS, and Android for convenient monitoring from anywhere.
- Wide Operating Temperature: Functions effectively in temperatures ranging from -22°F to 140°F.
- Power Options: Supports DC12V and PoE (802.3af, ?6W) for flexible installation.
- Built-in MIC: Captures audio alongside video, providing a more comprehensive monitoring solution.
- MicroSD Card Slot: Allows for standalone recording, adding flexibility and security.
- Built-in Reset Button: Facilitates easy restoration of factory settings when necessary.
- NDAA Compliant: Meets compliance standards for governmental procurement, ensuring reliability and trust.
AVYCON AVC-NCB51M Detailed Specifications
| Camera Type | 5 Megapixel H.265 Outdoor Bullet Camera |
| Max Resolution | 2880 x 1620 pixels |
| Lens Type | Motorized 2.8-12mm Lens |
| IR Distance | Up to 114 ft. |
| Power Supply | DC12V / PoE (802.3af, ?6W) |
| Temperature Range | -22°F to 140°F |
| MicroSD Slot | Yes, for standalone recording |
| Audio | Built-in Microphone |
| Compliance | NDAA Compliant |
SKU  | AVC-NCB51M |
|---|---|
| Features | Audio, Auto Gain Control, Automatic White Balance, Back Light Compensation, Day/Night, Digital Noise Reduction, Mirror, Motion Detection Tracking, ONVIF, Privacy Masking, Weather Resistant, Wide Dynamic Range |
| Manufacturer | Avycon |
| NDAA | Compliant |
Camera Signal  | Network IP |
| Connection Type | Wired |
| Infrared Distance | 101 Feet + |
| Resolution | 5 Megapixel |
| Lens Type | Varifocal |
| Lens Size | 2.8-12mm |
| Mount Type | Ceiling, Wall |
| Compression Method | H.264, H.265 |
| Durability | Weather Resistant |
| Voltage | 12vDC, PoE |
| Automatic Gain Control (AGC) | Auto |
| Dimensions (W x H) | 11.63” × ø4.25”(295.37mm × ø108mm) |
| Electronic Shutter | 1/5s ~ 1/20,000s |
| Image Device | 1/2.7" Progressive CMOS |
| IR LEDs | 4 |
| Minimum Scene Illumination | Color: 0.02 lux @ F1.2 (AGC ON); BW: 0 lux w/ IR ON |
| Operating Humidity | ≤95%RH |
| Operating Temperature | -22°~140°F (-30°~60°Celsius) |
| Privacy Zone | Off/On (4 Zone, Rectangle) |
| Protocols | TCP/IP, HTTP, DHCP, DNS, DDNS, RTP/RTSP, SMTP, NTP, UPnP, SNMP, HTTPS, FTP |
| Weatherproof | IP66 |
| Digital Noise Reduction | 3D DNR |
| Mirror | Flip / Rotation |
| Angle of View | Horizontal: 112.6°, Vertical: 58.5°, Diagonal: 138° |
| Motion Detection Tracking | Off/On (8 Level) |
| Back Light Compensation | Off/On (5 Zone) |
| Automatic White Balance | Auto/Manual |
| IR Distance | 35m/114ft |
| Audio | Yes |
| Auto Gain Control | Yes |
| Day/Night | Yes |
| Digital Noise Reduction | Yes |
| Automatic White Balance | Yes |
| Back Light Compensation | Yes |
| Motion Detection Tracking | Yes |
| Privacy Masking | Yes |
| Wide Dynamic Range | Yes |
| Mirror | Yes |
| ONVIF | Yes |
