Arecont Vision AV02CMB-100 2.1 Megapixel Day/Night IR Indoor/Outdoor Bullet IP Camera, 3.6mm Lens
SKU
AV02CMB-100
Model No
AV02CMB-100
$205.92
Product Highlights
- 1080p (2.1MP) Resolution
- 3.6mm Integrated Lens
- SNAPstream Capability to Reduce Bandwidth without Impacting Image Quality
- NightView for Strong Low Light Performance
- True Day/Night Functionality with Mechanical IR Cut Filter
Speak to an expert
The AV02CMB-100 from Arecont Vision is a powerful 2.1 Megapixel Day/Night IR Indoor/Outdoor Bullet IP Camera designed for optimal performance in all lighting conditions. With features such as 1080p resolution, SNAPstream technology for bandwidth efficiency, and enhanced WDR for superior image quality, this camera proves to be a top choice for surveillance needs. Its robust housing and advanced night vision capabilities ensure reliable monitoring, regardless of the environment.
Arecont Vision AV02CMB-100 Camera Features
- 1080p (2.1MP) Resolution: Provides clear, high-quality images for detailed surveillance.
- 3.6mm Integrated Lens: Ideal focal length for versatile monitoring applications.
- SNAPstream Capability: Reduces bandwidth consumption significantly without compromising image quality.
- NightView: Ensures strong low light performance with enhanced sensitivity for capturing critical details.
- True Day/Night Functionality: Mechanical IR cut filter enables automated switching for day and night surveillance.
- Enhanced WDR up to 120dB: Allows for clear images in both shaded and brightly lit areas simultaneously.
- CorridorView: 90° image rotation technology enhances coverage in narrow spaces like hallways.
- Advanced Features: Includes privacy mask, motion detection, bit rate control, and forensic zooming.
- On-Screen Display (OSD): Provides user-friendly access to camera settings and information.
- Defog Technology: Improves visibility in foggy or hazy conditions.
- Triple Encoder: Supports H.265, H.264, and MJPEG formats for flexible video streaming.
- Comprehensive Network Protocols: Compatible with SNMP, HTTPS, IPv6, and more for diverse network applications.
- All-in-One H.265/H.264 PoE Solution: Simplifies installation with Power-over-Ethernet capability.
- Integrated IR LEDs: Provides superior night illumination while preventing over-exposure.
- IK-10 Impact-Resistant Housing: Durable design withstands high levels of physical stress.
- Outdoor Rated IP66: Ensures reliable performance in harsh weather conditions.
- Easily Adjustable 3-Axis Wall Mount: Simplifies installation and positioning for optimal coverage.
Arecont Vision AV02CMB-100 Detailed Specifications
| Camera Type | Indoor/Outdoor Bullet IP Camera |
| Resolution | 1080p (2.1MP) |
| Lens | 3.6mm Integrated Lens |
| Day/Night Functionality | True Day/Night with Mechanical IR Cut Filter |
| WDR | Enhanced WDR up to 120dB |
| Low Light Sensitivity | NightView Technology |
| Housing Material | Cast-Aluminum, IK-10 Rated |
| Environmental Rating | IP66 Rated for Outdoor Use |
| Power Supply | Power-over-Ethernet (PoE - IEEE 802.3af) |
| Network Protocols | SNMP, HTTPS, IPv6, DHCP, 802.1x, and more |
| Video Compression | Triple Encoder: H.265/H.264/MJPEG |
| Special Features | CorridorView, Privacy Mask, Motion Detection, Defog Technology |
SKU  | AV02CMB-100 |
|---|---|
| Features | Auto Gain Control, Automatic White Balance, Back Light Compensation, Day/Night, Mirror, Motion Detection Tracking, On Screen Display Menu, ONVIF, Privacy Masking, Wide Dynamic Range |
| Manufacturer | Arecont Vision |
Camera Signal  | Network IP |
| Connection Type | Wired |
| Infrared Distance | 61~100 Feet |
| Resolution | 2.1 Megapixel |
| Lens Type | Fixed |
| Mount Type | Ceiling, Wall |
| Compression Method | H.264, MPEG-4, M-JPEG, H.265 |
| Durability | Indoor, Vandal Resistant, Weather Resistant |
| Voltage | PoE |
| Automatic Gain Control (AGC) | Auto |
| Dimensions (W x H) | 2.8" H (71.5mm) x 3.39" W (86mm) x 6.8" D (172.8mm) |
| Electronic Shutter | Auto/manual 0.1ms ~ 500ms |
| Image Device | 1/2.8" CMOS Progressive Sensor |
| IR LEDs | 4 |
| Minimum Scene Illumination | Color (Day Mode): 0.05 Lux, B/W (Night Mode): 0.005 Lux |
| Operating Humidity | 0% to 90% (non-condensing) |
| Operating Temperature | -20°C (-4°F) to +50°C (122°F) |
| Power Consumption | 7.5W PoE max |
| Privacy Zone | Unlimited |
| Protocols | SNMP, HTTP, HTTPS, IPv6, IPv4, SSL, TCP/IP, UPnP, UDP, RTCP, RTSP, RTP, SMTP, NTP, DHCP, FTP, 802.1x, Zero Configure |
| Weatherproof | IP66 |
| Angle of View | H-FOV = 85°, V-FOV = 46° |
| Rotation Angle | 90°, 180°, and 270° image rotation |
| Motion Detection Tracking | Real-time, 1024 detection zones |
| Back Light Compensation | Auto |
| Automatic White Balance | Auto/manual |
| IR Distance | 20m/66ft |
| Auto Gain Control | Yes |
| Day/Night | Yes |
| Automatic White Balance | Yes |
| Back Light Compensation | Yes |
| Motion Detection Tracking | Yes |
| On Screen Display Menu | Yes |
| Privacy Masking | Yes |
| Wide Dynamic Range | Yes |
| Mirror | Yes |
| ONVIF | Yes |
