Axis 5715C002 VB-H47B 1.3 Megapixel Network Indoor PTZ Camera with 20X Lens
SKU
5715C002
Model No
VB-H47B
$3,042.43
Product Highlights
Speak to an expert
The VB-H47B Full HD PTZ IP security camera combines a powerful 20x optical zoom, excellent low-light capability, WDR (Wide Dynamic Range) function, and fast auto-focus to deliver comprehensive indoor monitoring. Its flexible installation options make it suitable for various indoor environments.
Axis 5715C002 VB-H47B Camera Features
- Full HD PTZ IP security camera: Delivers high clarity and detail for reliable indoor monitoring.
- Powerful 20x optical zoom lens: Allows for detailed observation from a distance, supplemented by 16x digital zoom and fast autofocus.
- Remarkable low-light performance: Enables color recording at 0.02 lux and mono at 0.003 lux, ensuring visibility of subjects during nighttime.
- WDR performance: Captures clear images in scenes with contrasting light conditions, enhancing visibility in bright and dark areas.
- Fast PTZ capability: Provides smooth and precise movement to programmed pre-set positions for effective coverage.
- High-definition video streaming: Outputs full HD 60 fps video and supports simultaneous five streams, including two H.265 or H.264 streams for flexible use.
- ONVIF Profile-S/G/T compliant: Ensures interoperability with a wide range of security systems and devices.
Axis 5715C002 VB-H47B Detailed Specifications
| Camera Type | Network Indoor PTZ Camera |
| Resolution | 1.3 Megapixel |
| Optical Zoom | 20x |
| Digital Zoom | 16x |
| Low-Light Performance | Color at 0.02 lux, Mono at 0.003 lux |
| WDR Function | Wide Dynamic Range Enabled |
| Pan/Tilt/Zoom Speed | Fast, high-precision PTZ capability |
| Video Frame Rate | 60 fps |
| Streaming Capabilities | Simultaneous five streams, including two H.265 or H.264 |
| Compliance | ONVIF Profile-S/G/T Compliant |
SKU  | 5715C002 |
|---|---|
| Features | Audio, Auto Gain Control, Automatic White Balance, Day/Night, Digital Zoom, Flickerless, ONVIF, Privacy Masking, Wide Dynamic Range |
| Manufacturer | Axis |
Camera Signal  | Network IP |
| Connection Type | Wired |
| Infrared Distance | Non Infrared |
| Resolution | 1.3 Megapixel |
| Lens Type | Motorized Zoom |
| Lens Size | 20X |
| Mount Type | Ceiling, Wall |
| Compression Method | H.264, JPEG, H.265 |
| Durability | Indoor |
| Voltage | PoE |
| Dimensions (W x H) | (Φx H) Φ132 x 155 mm (Φ5.20 x 6.10 in.) |
| Electronic Shutter | 1/1, 1/2, 1/4, 1/8, 1/13, 1/15, 1/25, 1/30, 1/50, 1/60, 1/100, 1/120, 1/250, 1/360, 1/500, 1/720, 1/1000, 1/1400, 1/2000, 1/3000, 1/4000, 1/6000, 1/8000, 1/10000, 1/16000 sec |
| Image Device | 1/2.8 type CMOS |
| Minimum Scene Illumination | Day Mode (color): 0.02 lux (F1.6, shutter speed 1/30 sec., 50IRE), Night Mode (monochrome): 0.003 lux (F1.6, shutter speed 1/30 sec., 50IRE) |
| Operating Humidity | 5% – 85% (without condensation) |
| Operating Temperature | -10°C – +50°C (+14°F – +122°F) |
| Angle of View | For 16:9 aspect ratios: Horizontal: 62.4° (W) – 3.3° (T) Vertical: 36.3° (W) – 1.9° (T), For 4:3 aspect ratios: Horizontal: 47.9° (W) – 2.5° (T) Vertical: 36.3° (W) – 1.9° (T) |
| Automatic White Balance | Auto/Manual |
| Audio | Yes |
| Auto Gain Control | Yes |
| Day/Night | Yes |
| Automatic White Balance | Yes |
| Flickerless | Yes |
| Privacy Masking | Yes |
| Wide Dynamic Range | Yes |
| ONVIF | Yes |
| Digital Zoom | Yes |
