MuxLab 500792 2 Megapixel Network Pedestal PTZ Camera with 12X Lens
SKU
500792
Model No
500792
$657.00
Product Highlights
- AV over IP MuxStream Camera supports up to 1920 x 1080 (Full HD) at 60Hz video streams
- Low bandwidth streaming via an H.264/265 video codec, excellent for LAN & Internet transmission
- High image quality and <200ms latency in low latency mode with H.265
- Supports TCP/IP, HTTP, RTSP, RTMP, Onvif, DHCP, and Multicast protocols
- Includes wireless clip-on Lav (Lavalier) Mic with transmitter and receiver
Speak to an expert
The MuxLab 500792 2 Megapixel Network Pedestal PTZ Camera with 12X Lens offers a comprehensive live streaming solution, combining high-definition video quality with user-friendly controls and support for various streaming platforms. Ideal for broadcasting presentations, this camera ensures excellent video performance through its advanced features, making it an essential tool for content creators, educators, and professionals alike.
MuxLab 500792 Key Features
- High Resolution: Supports up to 1920 x 1080 (Full HD) at 60Hz, ensuring crystal-clear video quality for professional-grade broadcasts.
- Efficient Streaming: Utilizes H.264/265 video codec for low bandwidth usage, making it perfect for both LAN and Internet transmission.
- Low Latency: Achieves high image quality with less than 200ms latency in low latency mode using H.265, providing seamless viewing experiences.
- Protocol Support: Compatible with TCP/IP, HTTP, RTSP, RTMP, Onvif, DHCP, and Multicast protocols for versatile connectivity options.
- Wireless Audio: Includes a wireless clip-on Lavalier microphone system, enabling high-quality audio capture for live events.
- User-Friendly App: Managed with the free MuxLab MuxStream Control App, available for iOS and Android tablets, and Windows PC, facilitating easy setup and control.
Detailed Specifications for MuxLab 500792
| Camera Type | PTZ (Pan-Tilt-Zoom) |
| Image Sensor | 2 Megapixel |
| Video Resolution | 1920 x 1080 (Full HD) |
| Frame Rate | 60Hz |
| Video Codec | H.264/265 |
| Latency | <200ms (low latency mode) |
| Streaming Protocols | TCP/IP, HTTP, RTSP, RTMP, Onvif, DHCP, Multicast |
| Microphone | Wireless Lavalier Mic with transmitter and receiver |
| Control App | MuxLab MuxStream Control App (iOS, Android, Windows) |
SKU  | 500792 |
|---|---|
| Features | Audio, Auto Gain Control |
| Manufacturer | MuxLab |
Camera Signal  | Network IP |
| Connection Type | Wired |
| Infrared Distance | Non Infrared |
| Resolution | 2 Megapixel |
| Lens Type | Motorized Zoom |
| Lens Size | 12X |
| Mount Type | Pedestal |
| Compression Method | H.264, H.265 |
| Voltage | 12vDC |
| Dimensions (W x H) | (W x D x H) = 12.204” (310mm) x 5.708” (145mm) x 9.448” (240mm) |
| Operating Humidity | Up to 95% non-condensing |
| Operating Temperature | Operating: -10° to 40°C Storage: -20° to 60°C |
| Protocols | TCP/IP, HTTP, RTSP, RTMP, Onvif, DHCP, Multicast |
| Audio | Yes |
| Auto Gain Control | Yes |
| Digital Zoom | Yes |
