Axis 2546C001 2.1 MP Indoor PTZ Network Mini Dome Camera 4X Lens
SKU
2546C001
Model No
CANON NETWORK CAMERA VB-S31D MkII
$655.19
Product Highlights
- Full HD at 30fps for clear, detailed images
- CMOS sensor delivers high performance in low light
- Wide angle F/1.6 Canon lens offers a 95.0° Angle of View
- Multi-streaming of MJPEG and H.264 video in Full HD or lower resolutions
- Direct recording / playback from microSD card (64 GB)
Speak to an expert
The 2546C001 from Axis is a PT Minidome full HD network security camera with ultra-compact lens technology. Ideal for indoor security in retail, education and business environments.
Features
- Full HD at 30fps: delivers clear, detailed images for effective monitoring.
- High-Performance CMOS Sensor: excels in low light conditions, ensuring visibility at all times.
- Wide Angle Canon Lens: with a 95.0° Angle of View, captures more area with fewer cameras.
- Multi-Streaming Capability: support for MJPEG and H.264 video in Full HD or lower resolutions allows for flexible viewing options.
- MicroSD Card Recording: enables direct recording and playback from a 64 GB microSD card for added convenience.
- Auto Smart Shade Control: optimizes exposure for varying environments, enhancing image clarity.
- Data Reduction Technologies: Motion Adaptive Noise Reduction and Area-Specific Data Size Reduction maintain high image quality while reducing data size.
- Intelligent Analytics Functions: built-in features allow for efficient alarm detection, enhancing security measures.
- Remote Monitoring Capability: permits live monitoring and configuration via supported web browsers and mobile devices.
- ONVIF® Profile S Compliance: ensures interoperability with other security products.
- Compact Design: 120 mm diameter and 54 mm height make it easy to install in various settings.
Axis 2546C001 Camera Features
Detailed Camera Specifications
| Feature | Details |
|---|---|
| Model | Axis 2546C001 |
| Resolution | 2.1 MP |
| Frame Rate | 30fps |
| Lens Type | 4X Zoom |
| Operating Temperature | -20°C to 50°C |
| Dimensions | 120 mm diameter, 54 mm height |
| Weight | 480 g |
| Power Supply | PoE |
| Network Protocols | IPv4, IPv6, TCP, UDP, HTTP, HTTPS, and more |
| Audio Support | Two-way audio support |
SKU  | 2546C001 |
|---|---|
| Features | Audio, Auto Gain Control, Automatic White Balance, Day/Night, Digital Noise Reduction, Digital Zoom, Flickerless, On Screen Display Menu, ONVIF, Privacy Masking |
| Manufacturer | Axis |
Camera Signal  | Network IP |
| Connection Type | Wired |
| Infrared Distance | Non Infrared |
| Resolution | 2.1 Megapixel |
| Lens Type | Fixed |
| Lens Size | 2.7mm |
| Mount Type | Ceiling, Wall |
| Compression Method | H.264, M-JPEG |
| Durability | Indoor |
| Voltage | PoE |
| Dimensions (W x H) | (Φ x H) Φ120 x 54 mm (Φ4.72 x 2.13 in.) |
| Electronic Shutter | 1, 1/2, 1/4, 1/8, 1/15, 1/30, 1/50, 1/60, 1/100, 1/120, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/8000, 1/10000, 1/16000 sec |
| Image Device | 1/3 type CMOS (primary colour filter) |
| Minimum Scene Illumination | Day Mode (colour): 0.45 lux (F1.6, shutter speed 1/30 sec., SSC off, 50IRE)Night Mode (monochrome): 0.25 lux (F1.6, shutter speed 1/30 sec., SSC off, 50IRE) |
| Operating Humidity | 5% – 85% (without condensation) |
| Operating Temperature | -10°C – +50°C (+14°F – +122°F) |
| OSD Menu | Number of registration: Max. 8 places, Number of mask colours: 1 (select from 9 colours) |
| Power Consumption | Max. 7.6 W |
| Protocols | IPv4, IPv6, TCP/IP, UDP, HTTP, FTP, SNMPv1/v2c/v3 (MIB2), DHCP, DNS, AutoIP, mDNS, ARP, ICMP, POP3, NTP, SMTP, RTP/RTCP, RTSP, SSL/TLS, IPsec, ONVIF, WV-HTTP |
| Scanning System | Progressive |
| Angle of View | For 16:9 aspect ratios: Horizontal: 95.0° Vertical: 60.0° For 4:3 aspect ratios: Horizontal: 76.0° Vertical: 60.0° |
| Automatic White Balance | Auto / Manual Daylight Fluorescent / White Fluorescent / Warm Fluorescent / Mercury Lamp / Sodium Lamp / Halogen Lamp Manual: One-shot WB / R Gain / B Gain |
| Audio | Yes |
| Auto Gain Control | Yes |
| Day/Night | Yes |
| Digital Noise Reduction | Yes |
| Automatic White Balance | Yes |
| Flickerless | Yes |
| On Screen Display Menu | Yes |
| Privacy Masking | Yes |
| ONVIF | Yes |
| Digital Zoom | Yes |
