Axis 02769-021 D2210-VE 60 GHz Radar for Area and Traffic Monitoring 24/7
SKU
02769-021
Model No
02769-021
$4,353.58
Product Highlights
- 4 MP and 10x optical zoom
- Continuous 360° pan
- Support for analytics with deep learning
- Compact design
- PoE or 24 V with audio and I/O connectivity
Speak to an expert
Introducing the Axis 02769-021 D2210-VE 60 GHz Radar, a sophisticated solution designed for area and traffic monitoring with 24/7 reliability. This compact radar system combines advanced analytics and deep learning capabilities to deliver precise monitoring in various environments, ensuring you never miss a moment.
Axis 02769-021 D2210-VE Camera Features
- 4 MP and 10x optical zoom: Offers exceptional image quality and versatility, allowing you to capture both wide views and detailed close-ups.
- Continuous 360° pan: Provides comprehensive coverage with seamless rotation, ensuring complete situational awareness.
- Support for analytics with deep learning: Enables real-time processing and intelligent analysis, enhancing security measures and operational efficiency.
- Compact design: Designed for easy installation and integration into various environments, both indoors and outdoors.
- PoE or 24 V with audio and I/O connectivity: Flexibly connects with power-over-Ethernet or 24-volt supplying options, plus integrates with external devices for extended functionality.
Detailed Specifications for Axis 02769-021 D2210-VE
| Image Resolution | 4 MP |
| Optical Zoom | 10x |
| Pan Range | 360° continuous |
| Installation Compatibility | Axis PTZ mounts |
| Deep Learning Processing Unit | Yes |
| Audio Connectivity | Yes |
| Data Protection | Axis Edge Vault |
| Cybersecurity | Hardware-based |
SKU  | 02769-021 |
|---|---|
| Features | Audio, Auto Gain Control, Automatic White Balance, Day/Night, Digital Noise Reduction, Motion Detection Tracking, ONVIF, Privacy Masking, Vandal Resistant, Weather Resistant, Wide Dynamic Range |
| Manufacturer | Axis |
| Connection Type | Wired |
Resolution  | 4 Megapixel |
| Lens Type | Motorized Zoom |
| Lens Size | 10X |
| Mount Type | Ceiling, Wall |
| Compression Method | H.264, MPEG-4 |
| Durability | Vandal Resistant, Weather Resistant |
| Voltage | 20-28vDC, PoE |
| Electronic Shutter | 1/17000 s to 0.2 s @ 25/30 fps 1/27000 s to 0.2 s @ 50/60 fps |
| Image Device | 1/3” progressive scan RGB CMOS |
| Image Pixels Total | 1.998 µm |
| Minimum Scene Illumination | Color: 0.20 lux at 30 IRE, F1.6, B/W: 0.01 lux at 30 IRE, F1.6, Color: 0.25 lux at 50 IRE, F1.6, B/W: 0.01 lux at 50 IRE, F1.6 |
| Operating Humidity | 15–100% RH (condensing) |
| Operating Temperature | -20 °C to 50 °C (-4 °F to 122 °F) |
| Power Consumption | max 4.2 W, max 12.95 W |
| S/N Ratio | 55 dB |
| Weatherproof | IP66, IK09 |
| Zoom Ratio | 12x |
| Digital Noise Reduction | Spatial filter (2D noise reduction), Temporal filter (3D noise reduction) |
| Angle of View | Horizontal field of view: 59.1°–6.5°, Vertical field of view: 35°–3.67° |
| Audio | Yes |
| Auto Gain Control | Yes |
| Day/Night | Yes |
| Digital Noise Reduction | Yes |
| Automatic White Balance | Yes |
| Motion Detection Tracking | Yes |
| Privacy Masking | Yes |
| Wide Dynamic Range | Yes |
| ONVIF | Yes |
