Axis 02669-001 Q2101-TE Network 384 X 288 Outdoor Thermal Imaging Camera with 19mm Lens

SKU
02669-001
Model No
Q2101-TE
$5,023.51
Volume Discounts Volume
Discounts
Free System Design Free System
Design
Lifetime Tech Support Lifetime
Tech Support
Free Shipping Over $450* Free Shipping
Over $450*
Product Highlights
  • Thermometric guard tour capabilities
  • Early fire detection analytics
  • Spot temperature reading
  • Built-in cybersecurity features
  • Support for edge-to-edge technology

Ideal for large-scale temperature monitoring, this dependable Axis 02669-001 Q2101-TE Network Outdoor Thermal Imaging Camera with 19mm Lens lets you remotely monitor temperatures from -40 °C to 350 °C (-40 °F to 660 °F). You’ll know if your equipment is close to overheating and can act to avoid unwanted downtime. With the camera mounted on a positioning unit (sold separately) you can enable thermometric guard tour with up to 256 presets and 10 polygonal detection areas per preset. Robust and impact-resistant, it includes built-in cybersecurity features to help safeguard your system. Additionally, edge-to-edge technology lets you connect network speakers to enable audio alarms.

Axis 02669-001 Q2101-TE Camera Features

  • Thermometric guard tour capabilities: Enables sequential monitoring through 256 presets for enhanced oversight and rapid response to temperature changes.
  • Early fire detection analytics: Provides proactive measures by alerting you to potential fire risks before they escalate, ensuring safety.
  • Spot temperature reading: Allows for quick checks of specific areas or objects, providing instant data to help make informed decisions.
  • Built-in cybersecurity features: Protects sensitive data and ensures safe usage against cyber threats, giving you peace of mind.
  • Support for edge-to-edge technology: Facilitates connection with network speakers to enable audio alarms, enhancing alert systems when temperature thresholds are breached.

Detailed Specifications for Axis 02669-001 Q2101-TE

FeatureDetails
Camera TypeThermal Imaging
Resolution384 x 288
Temperature Range-40 °C to 350 °C (-40 °F to 660 °F)
Lens19mm
Guard Tour PresetsUp to 256
Polygonal Detection Areas10 per preset
Cybersecurity FeaturesBuilt-in
Audio Alarm SupportYes, with edge-to-edge technology
SKU  02669-001
Features  Audio, Auto Gain Control, Mirror, Motion Detection Tracking, ONVIF, Privacy Masking, Vandal Resistant, Weather Resistant, Wide Dynamic Range
Manufacturer  Axis
Camera Signal     Network IP
Connection Type  Wired
Infrared Distance    Non Infrared
Resolution    384 X 288
Lens Type    Fixed
Lens Size    19mm
Mount Type  Bracket Required
Compression Method    H.264, M-JPEG, H.265
Durability    Vandal Resistant, Weather Resistant
Voltage  PoE
Image Device    Uncooled microbolometer 384x288 pixels, pixel size 17 μm. Spectral range: 8-14 μm
Operating Humidity    10–100% RH (condensing)
Operating Temperature    -40 °C to 50 °C (-40 °F to 122 °F)
Weatherproof    IP66/IP67
Angle of View    Horizontal field of view: 19.4°, F1.23
AudioYes
Auto Gain Control    Yes
Motion Detection Tracking    Yes
Privacy Masking    Yes
Wide Dynamic Range    Yes
Mirror    Yes
ONVIF  Yes
