Axis 02413-001 P5676-LE 4 Megapixel Outdoor IR PTZ Camera with 30X Lens
SKU
02413-001
Model No
P5676-LE
$2,104.53
Product Highlights
- 4 MP with 30x optical zoom
- Forensic WDR, Lightfinder 2.0, IR Illumination
- Support for advanced analytics
- Built-in cybersecurity features
- Zipstream with support for H.264/H.265
Speak to an expert
This high-performance PTZ camera offers 4 MP image quality with 30x optical zoom and IR. Forensic WDR and Lightfinder 2.0 guarantee images with saturated colors and sharp details of moving objects even in challenging light or near darkness. It offers support for analytics and includes AXIS Object Analytics to detect and classify people and vehicles. This cost-effective camera includes built-in cybersecurity features to safeguard your system and prevent unauthorized access. Axis Zipstream with H.264/H.265 significantly lowers bandwidth and storage requirements. Furthermore, you can pop it into an AXIS Q6100-E using AXIS TP6902-E Adapter Bracket and enjoy 360° overview for total situational awareness.
Axis 02413-001 P5676-LE Camera Features
- 4 MP with 30x optical zoom: Provides excellent image quality and the ability to capture distant objects in detail.
- Forensic WDR, Lightfinder 2.0, IR Illumination: Ensures clarity and color accuracy in various lighting conditions, including low light.
- Support for advanced analytics: Enhances security by enabling detection and classification of people and vehicles.
- Built-in cybersecurity features: Protects the camera from unauthorized access and ensures data integrity.
- Zipstream with support for H.264/H.265: Reduces bandwidth and storage needs while maintaining high-quality video streams.
Axis 02413-001 P5676-LE Detailed Specifications
| Image Sensor | 4 Megapixel |
| Optical Zoom | 30x |
| IR Illumination | Yes |
| WDR Technology | Forensic WDR |
| Analytics Support | AXIS Object Analytics |
| Cybersecurity Features | Built-in |
| Compression | H.264/H.265 |
| Mounting Options | Compatible with AXIS Q6100-E using AXIS TP6902-E Adapter Bracket |
SKU  | 02413-001 |
|---|---|
| Features | Audio, Auto Gain Control, Automatic White Balance, Day/Night, Motion Detection Tracking, ONVIF, Privacy Masking, Vandal Resistant, Weather Resistant, Wide Dynamic Range |
| Manufacturer | Axis |
Camera Signal  | Network IP |
| Connection Type | Wired |
| Infrared Distance | 101 Feet + |
| Resolution | 4 Megapixel |
| Lens Type | Motorized Zoom |
| Lens Size | 30X |
| Mount Type | Wall |
| Compression Method | H.264, MPEG-4, M-JPEG, H.265 |
| Durability | Vandal Resistant, Weather Resistant |
| Voltage | PoE |
| Dimensions (W x H) | Height: 242 mm (9.53 in), ø 205 mm (8.1 in) |
| Electronic Shutter | 1/50000 s to 1/5 s with 50 Hz, 1/62500 s to 1/5 s with 60 Hz |
| Image Device | 1/2.9” progressive scan RGB CMOS |
| IR Wavelength | 850 nm |
| Minimum Scene Illumination | Color: 0.1 lux at 30 IRE F1.6, B/W: 0.01 lux at 30 IRE F1.6, 0 lux with IR illumination on, Color: 0.11 lux at 50 IRE F1.6, B/W: 0.03 lux at 50 IRE F1.6, 0 lux with IR illumination on |
| Operating Humidity | 10–100% RH (condensing) |
| Operating Temperature | -30 °C to 50 °C (-22 °F to 122 °F) |
| Power Consumption | Camera consumption: typical 13 W (no IR), max 25.5 W IEEE 802.3at Type 2 Class 4, Camera consumption: typical 13 W (no IR), max 29 W IEEE 802.3bt Type 3 Class 6 |
| Weatherproof | IP66 |
| Angle of View | Horizontal field of view: 57.1°- 2.1°, Vertical field of view: 34.4°- 1.2° |
| IR Distance | 200m/656ft |
| Audio | Yes |
| Auto Gain Control | Yes |
| Day/Night | Yes |
| Automatic White Balance | Yes |
| Motion Detection Tracking | Yes |
| Privacy Masking | Yes |
| Wide Dynamic Range | Yes |
| ONVIF | Yes |
