Axis 02363-021 F7225-RE 2 Megapixel Pinhole Sensor Modular Camera with 3.7mm Lens, 8 Pieces
SKU
02363-021
Model No
F7225-RE
$2,286.37
Product Highlights
- Extremely discreet design
- Up to 60 fps at 1080p
- Up to 180 fps at 720p
- 97º horizontal field of view
- Forensic WDR
Speak to an expert
Ideal for integration in tight spaces such as machines or ATMs, this extremely discreet sensor is designed for use with AXIS F91 main units to ensure lower installation and configuration costs. It supports four HDTV 1080p video streams at 30 fps or 720p video streams at up to 60 fps. When used with AXIS F9111 main unit, it delivers HDTV 1080p video streams at 60 fps or 720p video streams at up to 180 fps. This IP66-/IP67-rated sensor supports a wide temperature range. Furthermore, it offers a 97º field of view for wide area coverage.
Axis 02363-021 F7225-RE Camera Features
- Discreet Design: The compact sensor fits perfectly in tight spaces, maintaining security without drawing attention.
- High Frame Rates: Supports up to 60 fps at 1080p and 180 fps at 720p, ensuring smooth video playback and high-quality footage.
- Wide Field of View: The 97º horizontal field of view covers larger areas, reducing the number of cameras needed for surveillance.
- Forensic WDR: Enhanced image quality in challenging lighting conditions, providing clearer details in both bright and dark areas.
- Durable Build: With an IP66/IP67 rating, this camera is resistant to dust and water, suitable for various environments.
Detailed Specifications for Axis 02363-021 F7225-RE
| Model | Axis 02363-021 F7225-RE |
| Resolution | 2 Megapixels |
| Lens | 3.7mm |
| Video Streaming | 4x 1080p at 30 fps or 720p up to 60 fps |
| Field of View | 97º horizontal |
| WDR Technology | Forensic WDR |
| Environmental Rating | IP66/IP67 |
| Temperature Range | Wide range suitable for various environments |
SKU  | 02363-021 |
|---|---|
| Features | Auto Gain Control, Day/Night, Weather Resistant, Wide Dynamic Range |
| Manufacturer | Axis |
Camera Signal  | Network IP |
| Connection Type | Wired |
| Infrared Distance | Non Infrared |
| Resolution | 2 Megapixel |
| Lens Type | Fixed |
| Lens Size | 3.7mm |
| Mount Type | Bracket Required |
| Compression Method | H.264, H.265 |
| Durability | Weather Resistant |
| Dimensions (W x H) | 45 x 25 x 20 mm (1.8 x 0.98 x 0.79 in) |
| Electronic Shutter | With AXIS F9111: 1080p, 25/30 fps: 1/20000 s to 1.5 s, 1080p, 50/60 fps: 1/27000 s to 1 s, HDTV 720p, 175/180 fps: 1/32500 s to 0.5 s, With AXIS F9104-B, F9114 and F9114-B: 1080p, 25/30 fps: 1/20000 s to 1.5 s HDTV 720p, 50/60 fps: 1/32500 s to 0.5 s |
| Image Device | 1/2.8” (effective) progressive scan RGB CMOS |
| Minimum Scene Illumination | Color: 0.3 lux at 50 IRE, F2.5 |
| Operating Humidity | 10-85% RH (non-condensing) |
| Operating Temperature | -30 °C to 55 °C (-22 °F to 131 °F) |
| Power Consumption | Typical 0.9 W, max 1.9 W |
| Weatherproof | IP66, IP67 |
| Angle of View | For 1080p: Horizontal field of view: 97°, Vertical field of view: 48°, For 720p: Horizontal field of view: 58°, Vertical field of view: 31° |
| Auto Gain Control | Yes |
| Day/Night | Yes |
| Wide Dynamic Range | Yes |
