Axis 02064-001 Q1615-LE Mk III 1080p Outdoor Network Box Camera, 2.8-8.5mm Lens

SKU
02064-001
Model No
Q1615-LE Mk III
$1,415.47
Volume Discounts Volume
Discounts
Free System Design Free System
Design
Lifetime Tech Support Lifetime
Tech Support
Free Shipping Over $450* Free Shipping
Over $450*
Product Highlights
  • -40 °C to 60 °C (-40 °F to 140 °F)
  • Lightfinder 2.0 and Forensic WDR
  • TPM, FIPS 140-2 level 2 certified
  • Embedded deep learning processing unit
  • Support for third-party deep learning applications

AXIS Q1615-LE Mk III combines exceptional imaging and video performance with outstanding hardware and processing capabilities. With up to 120 fps in HDTV 1080p, it captures excellent detailed images of fast-moving objects and people. This outdoor-ready camera features OptimizedIR for nighttime surveillance as well as remote zoom and focus for costefficient installation and maintenance. Enhanced security features such as signed firmware and secure boot ensure the integrity and authenticity of the firmware. Furthermore, it includes a deep learning processing unit enabling unique opportunities to take advantage of tailor-made third-party applications based on deep learning.

AXIS Q1615-LE Mk III Camera Features

  • High Frame Rate: Up to 120 fps in HDTV 1080p for capturing detailed images of fast-moving subjects.
  • OptimizedIR: Enhanced nighttime surveillance capabilities for clear imaging in low-light conditions.
  • Remote Zoom and Focus: Facilitates cost-efficient installation and maintenance by allowing adjustments from a distance.
  • Robust Outdoor Design: Operational in extreme temperatures from -40 °C to 60 °C (-40 °F to 140 °F).
  • Advanced Image Technology: Features Lightfinder 2.0 and Forensic WDR for exceptional image quality in varying lighting conditions.
  • Secure Architecture: Includes TPM and FIPS 140-2 level 2 certification to safeguard the device.
  • Deep Learning Processing Unit: Enables advanced analytics and support for third-party deep learning applications.

AXIS Q1615-LE Mk III Detailed Specifications

ModelAXIS Q1615-LE Mk III
Resolution1080p
Lens2.8-8.5mm
Frame RateUp to 120 fps
Temperature Range-40 °C to 60 °C (-40 °F to 140 °F)
Image TechnologyLightfinder 2.0, Forensic WDR
Security FeaturesTPM, FIPS 140-2 level 2 certified, signed firmware, secure boot
AnalyticsEmbedded deep learning processing unit
SKU  02064-001
Features  Audio, Auto Gain Control, Automatic White Balance, Day/Night, Mirror, Motion Detection Tracking, On Screen Display Menu, ONVIF, Privacy Masking, Vandal Resistant, Weather Resistant, Wide Dynamic Range
Manufacturer  Axis
Camera Signal     Network IP
Connection Type  Wired
Resolution    1080p
Lens Type    Varifocal
Lens Size    2.8-8.5mm
Mount Type  Ceiling, Wall
Compression Method    H.264, MPEG-4, M-JPEG, H.265
Durability    Vandal Resistant, Weather Resistant
Voltage  12vDC, PoE
Dimensions (W x H)  201 x 179 x 494 mm (7.9 x 7.1 x 19.4 in)
Electronic Shutter    1/125000 to 2 s
Image Device    1/2.8" Progressive scan RGB CMOS
IR Wavelength  850 nm
Minimum Scene Illumination  Color: 0.05 lux, B/W: 0.01 lux at 50 IRE, F1.2; Color: 0.1 lux, B/W: 0.02 lux at 50 IRE, F1.2; Color: 0.2 lux, B/W: 0.04 lux at 50 IRE, F1.2
Operating Humidity    10–100% RH (condensing)
Operating Temperature    -40 °C to 60 °C (-40 °F to 140 °F)
OSD Menu    English, German, French, Spanish, Italian, Russian, Simplified Chinese, Japanese, Korean, Portuguese, Traditional Chinese
Power Consumption  Max. 25.5 W, typical 13.7 W
Protocols  IPv4, IPv6 USGv6, HTTP, HTTP/2, HTTPSa, SSL/TLSa, QoS Layer 3 DiffServ, FTP, CIFS/SMB, SMTP, Bonjour, UPnPTM, SNMPv1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, SFTP, SRTP, TCP, UDP, IGMP, RTCP, ICMP, DHCPv4/v6, ARP, SOCKS, SSH, LLDP, MQTT, Syslog
Video Output    RJ45
Weatherproof    IP66, IP67
Angle of View    Horizontal field of view: 102°–40°, Vertical field of view: 58°–22°
Rotation AngleAuto, 0°, 90°, 180°, 270°
IR Distance  60m/196ft
AudioYes
Auto Gain Control    Yes
Day/Night    Yes
Automatic White Balance    Yes
Motion Detection Tracking    Yes
On Screen Display Menu    Yes
Privacy Masking    Yes
Wide Dynamic Range    Yes
Mirror    Yes
ONVIF  Yes
