Axis 01989-001 M3016 3 MP Explosion-Protected Network Camera with 2.8mm Lens
SKU
01989-001
Model No
M3016
$4,920.00
Product Highlights
- 3 MP at 30 fps, wide field-of-view, and WDR
- Lightweight and compact
- Powered by PoE with non-armored cable
- ATEX, IECEx, EAC Ex, and IA
- Zones 1, 2, 21, 22; Groups IIC, IIIC
Speak to an expert
ExCam XF M3016 comes enclosed in a stainless steel explosion-protected housing and is certified (ATEX/IECEx/EAC Ex/IA) for use in potentially combustible zones. This lightweight and robust fixed box camera features Wide Dynamic Range (WDR), a wide field-of-view and great 3 MP image quality at up to 30 fps. It offers easy one-person installation and thanks to its compact design, it easily fits wherever you need it. It’s powered by Power over Ethernet (PoE) and includes a pre-connected 5 m (16 ft) non-armored cable. Furthermore, Axis Zipstream with support for H.264 and H.265 significantly lowers bandwidth and storage requirements.
Axis 01989-001 M3016 Camera Features
- Image Quality: 3 MP at 30 fps provides clear and detailed images for accurate monitoring.
- Wide Field-of-View: Allows for extensive coverage with fewer cameras needed, saving on costs.
- Lightweight and Compact Design: Facilitates easy installation in various locations, perfect for tight spaces.
- Power over Ethernet (PoE): Simplifies setup by combining power and data into a single cable, reducing installation complexity.
- Explosion-Protected Certification: Certified for use in hazardous environments, ensuring safety and reliability.
Axis 01989-001 M3016 Detailed Specifications
| Image Sensor | 3 MP |
| Frame Rate | Up to 30 fps |
| Lens | 2.8mm |
| Field of View | Wide |
| Dynamic Range | Wide Dynamic Range (WDR) |
| Power Supply | Power over Ethernet (PoE) |
| Cable Length | 5 m (16 ft) non-armored cable |
| Certification | ATEX, IECEx, EAC Ex, IA |
| Zone Certifications | Zones 1, 2, 21, 22; Groups IIC, IIIC |
SKU  | 01989-001 |
|---|---|
| Features | Auto Gain Control, Automatic White Balance, Mirror, Motion Detection Tracking, ONVIF, Privacy Masking, Weather Resistant, Wide Dynamic Range |
| Manufacturer | Axis |
Camera Signal  | Network IP |
| Connection Type | Wired |
| Infrared Distance | Non Infrared |
| Resolution | 3 Megapixel |
| Lens Type | Fixed |
| Lens Size | 2.8mm |
| Mount Type | Bracket Required |
| Compression Method | H.264, MPEG-4, M-JPEG, H.265 |
| Durability | Weather Resistant |
| Voltage | PoE |
| Dimensions (W x H) | 179 x 79 x 96 mm (7.0 x 3.1 x 3.8 in) |
| Electronic Shutter | 1/32500 s to 1/5 s |
| Image Device | 1/3” progressive scan RGB CMOS |
| Minimum Scene Illumination | 0.4 lux at 50 IRE F2.0 |
| Operating Humidity | 10-100% RH (condensing) |
| Operating Temperature | -5 °C to 40 °C (23 °F to 104 °F) |
| Power Consumption | Typical 2.9 W, max 3.8 W |
| Weatherproof | IP68 |
| Angle of View | 4:3 aspect ratio: Horizontal: 69°, vertical: 52°, 16:9 aspect ratio: Horizontal: 92°, vertical: 52° |
| Auto Gain Control | Yes |
| Automatic White Balance | Yes |
| Motion Detection Tracking | Yes |
| Privacy Masking | Yes |
| Wide Dynamic Range | Yes |
| Mirror | Yes |
| ONVIF | Yes |
