Axis 01921-021 P3925-LRE BULK 10PCS 2 Megapixel IR Onboard Camera, 6mm Lens
SKU
01921-021
Model No
P3925-LRE BULK 10PCS
$9,541.03
Product Highlights
- Complies with EN50155 and EN45545-2
- IR illumination and EIS
- Lightfinder and Forensic WDR
- Low latency mode
- Built-in cybersecurity features
Speak to an expert
AXIS P3925-LRE specially designed for side view monitoring on buses, trains, and transportation vehicles. It can also be used for identifying maintenance needs on rolling stock, for example, wear and tear of pantograph collector strips. This robust and compact camera features a tempered glass window and complies with transport industry standards and IK10+, IP66, IP67, and IP6K9K. It delivers HDTV 1080p with Lightfinder for color images in poor light and Forensic WDR for maximal forensic usability in mixed light conditions. Plus, built-in IR Illumination enables monitoring in complete darkness. Furthermore, it supports exchangeable lenses for full flexibility.
Axis 01921-021 P3925-LRE Camera Features
- Compliance: Complies with EN50155 and EN45545-2, ensuring reliability in transportation environments.
- Illumination: IR illumination and EIS provide clear images even in complete darkness and reduce motion blur.
- Advanced Imaging: Features Lightfinder and Forensic WDR for enhanced image quality in low and mixed lighting conditions.
- Latency: Low latency mode improves live streaming and interaction.
- Cybersecurity: Built-in cybersecurity features help protect sensitive data from unauthorized access.
Axis 01921-021 P3925-LRE Detailed Specifications
| Model | Axis P3925-LRE |
| Resolution | 2 Megapixel (HDTV 1080p) |
| Lens | 6mm fixed lens |
| IR Illumination | Yes |
| Ingress Protection | IP66, IP67, IP6K9K |
| Impact Rating | IK10+ |
| Dimensions | Compact design for easy installation |
| Weight | Lightweight for transport applications |
| Operating Temperature | Wide operating temperature range suitable for transport environments |
SKU  | 01921-021 |
|---|---|
| Features | Auto Gain Control, Automatic White Balance, Day/Night, Heater & Fan, Mirror, ONVIF, Privacy Masking, Vandal Resistant, Weather Resistant, Wide Dynamic Range |
| Manufacturer | Axis |
Camera Signal  | Network IP |
| Connection Type | Wired |
| Infrared Distance | 61~100 Feet |
| Resolution | 2 Megapixel |
| Lens Type | Fixed |
| Lens Size | 6mm |
| Mount Type | Dashboard |
| Compression Method | H.264, M-JPEG, H.265 |
| Durability | Vandal Resistant, Weather Resistant |
| Voltage | PoE |
| Dimensions (W x H) | 160 x 116 x 63 mm (6.30 x 4.57 x 2.48 in) |
| Electronic Shutter | 1/33500 s to 2 s |
| Image Device | 1/2.9” Progressive scan RGB CMOS |
| IR Wavelength | 850 nm |
| Minimum Scene Illumination | Color: 0.07 lux at 30 IRE F1.9, B/W: 0.02 lux at 30 IRE F1.9, 0 lux with IR illumination on, Color: 0.14 lux at 50 IRE F1.9, B/W: 0.04 lux at 50 IRE F1.9, 0 lux with IR illumination on |
| Operating Humidity | 10-95% RH (non-condensing) |
| Operating Temperature | -40 °C to 55°C (-40 °F to 131°F) |
| Protocols | IPv4, IPv6 USGv6, HTTP, HTTPSb, HTTP/2, SSL/TLSb, QoS Layer DiffServ, FTP, SFTP, CIFS/SMB, SMTP, Bonjour, UPnP®, SNMP v1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, SRTP, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCPv4/v6, ARP, SOCKS, SSH, LLDP, MQTT v3.1.1, |
| Video Output | RJ45 |
| Weatherproof | IP66, IP67 |
| Angle of View | Horizontal field of view: 56°, Vertical field of view: 30° |
| Rotation Angle | ±175° |
| IR Distance | 20m/65.6ft |
| Auto Gain Control | Yes |
| Day/Night | Yes |
| Automatic White Balance | Yes |
| Heater & Fan | Yes |
| Privacy Masking | Yes |
| Wide Dynamic Range | Yes |
| Mirror | Yes |
| ONVIF | Yes |
