Bogen V60 Power Vector Modular Input Amplifier, 60W

The Bogen V60 Power Vector Modular Input Amplifier delivers exceptional performance with 60W of power and a versatile design featuring 8 module bays for a range of input and output options. With the ability to handle various speaker loads and a selection of advanced plug-in modules available, this amplifier enhances flexibility and reliability for any audio setup. The intelligent design automatically senses connected modules, making it an ideal choice for users needing an adaptable and powerful solution.

Bogen V60 Power Vector Amplifier Features

• Speaker Load Flexibility: Capable of handling 70V, 25V, 8-ohm, and 4-ohm speaker loads ensures compatibility with various speaker systems.
• Modular Design: 8 module bays allow for extensive input/output customization with advanced plug-in modules (sold separately).
• Dynamic Signal Management: 4 levels of priority between modules to prioritize signal paths based on your requirements.
• Signal Processing Capability: 2 module bays can handle plug-in signal processing output modules for enhanced audio management.
• Output Level Monitoring: 11-segment LED output level meter monitors output levels with Avg./Peak meter switch for precise audio tracking.
• Remote Control Volume: Motorized master volume control allows for remote operation convenience.
• Choice of Outputs: Lockable switch allows selection between transformer-coupled outputs or direct low-impedance output for flexibility.
• Easy Connections: 5-position barrier strip provides straightforward connections for speaker loads, ensuring easy setup.
• Bridging Capabilities: Bridging In/Out connector for linking multiple amplifiers or mixers for expanded audio distribution.
• Priority Mute Access: External access to priority mute buses gives you control over audio priorities when needed.
• Independent Volume Control: Allows for unique volume adjustments for each of the eight module bays.
• Clipping Indication: Two-color LED indicators for each channel to show input signal presence or clipping alerts.
• Built-in EQ Controls: Bass and treble control located in module bay 6 allows for tailored audio tuning.
• Signal Processing Insert Jacks: Let you connect external equipment for enhanced signal processing between pre-amp output and power amp input.
• Buffered Pre-EQ Output: Provides unbalanced buffered output signal for added connection versatility.
• Convenient AC Receptacle: Grounded, unswitched AC convenience receptacle with a 500W maximum capacity for powering external devices.
• Security Features: 8 module security cover/filler plates are included for added safety and aesthetics.
• Compact Design: 2 rack spaces high (3-1/2") makes it easy to integrate into existing setups.
• Safety Listed: Listed to UL Standard 60065 ensuring compliance with safety regulations for U.S. and Canada.
