Bogen V35 Power Vector Modular Input Amplifier, 35W

The V35 from Bogen is a power vector amplifier 35W with 8 module bays for a wide array of inputs and outputs. Modules are available for signal processing and inputs such as: balanced and unbalanced inputs; stereo or mono; telephone systems/PBXs; transformer-isolated; microphones; tone generator; and bridging. The Power Vector automatically senses each module and inserts it into the signal path. A 5-position barrier strip allows for 4/8ohm or 25/70V output loads. When you need an amplifier with flexibility and reliability, the Power Vector V35 is the obvious choice.

Bogen V35 Power Vector Amplifier Features

• Efficient Load Handling: Capable of handling 70V, 25V, 8-ohm, and 4-ohm speaker loads for versatile installation options.
• Modular Design: 8 module bays enable a customizable selection of advanced plug-in modules (modules sold separately) for enhanced functionality.
• Priority Levels: 4 levels of priority between modules ensure important signals are routed correctly based on precedence.
• Flexibility in Processing: 2 module bays that can accommodate plug-in signal-processing output modules for tailored sound adjustments.
• Real-time Level Monitoring: 11-segment LED output level meter allows for precise monitoring of amplifier output with Avg./Peak meter switch for various applications.
• Remote Control: Motorized master volume control can be remotely operated, providing convenient sound management from a distance.
• Output Selection: Lockable switch allows users to choose transformer-coupled outputs or a direct low-impedance output for specific needs.
• Secure Connections: 5-position barrier strip with clamping washers ensures reliable connections for speaker loads.
• Bridging Functionality: Bridging In/Out connector facilitates linking multiple amplifiers or mixers for expanded setups.
• Priority Mute Access: External access to priority mute buses enhances control over audio management.
• Channel Management: Independent volume control for each of the eight module bays provides customizable audio levels per channel.
• Signal Indication: Two-color LED for each channel indicates input signal presence or clipping, assisting in operational awareness.
• Equalization Control: Bass and treble control with a bypass switch (located in module bay 6) allows users to fine-tune sound quality.
• External Insertion Capability: Signal-processing insert jacks permit external equipment to be included between pre-amp output and power amp input for enhanced versatility.
• Convenience Receptacle: Grounded, unswitched AC convenience receptacle with a 500W maximum capacity provided for powering external equipment.
• Security Plates: 8 module security cover/filler plates included with the amplifier (PVMC) to maintain the integrity of the modular bays.
• Compact Size: Only 2 rack spaces high (3-1/2") allowing for easy integration into standard setups.
• Compliance Standards: Listed to UL Standard 60065 for U.S. and Canada ensuring safety and reliability standards are met.
