Bogen V150 Power Vector Modular Input Amplifier, 150W

The V150 from Bogen is a powerful 150W modular input amplifier featuring eight module bays for diverse input and output options. It supports various signal inputs, including balanced, unbalanced, and transformer-isolated sources, making it versatile for different settings. The amplifier automatically detects and integrates each module into the signal path, while its robust design allows for handling of varying speaker loads. For unparalleled flexibility and reliability, the Bogen Power Vector V150 is the ideal choice.

Bogen V150 Modular Amplifier Features

• Speaker Load Compatibility: Capable of handling 70V, 25V, 8-ohm, and 4-ohm speaker loads, providing flexibility for various installation scenarios.
• Modular Design: 8 module bays allow for a wide selection of advanced plug-in modules (sold separately), making it adaptable to specific needs.
• Priority Levels: 4 levels of priority between modules ensure that critical signals are prioritized during use.
• Signal Processing Flexibility: 2 bays can handle plug-in signal processing output modules for enhanced sound management.
• Output Monitoring: 11-segment LED output level meter provides real-time monitoring of the amplifier's output level with Avg./Peak meter switch.
• Remote Volume Control: Motorized master volume control enables remote operation for convenience.
• Output Options: Lockable switch allows selection between transformer-coupled outputs and direct low-impedance output, enhancing usability.
• Barrier Strip Connectivity: 5-position barrier strip with clamping washers for secure connections to speaker loads.
• Bridging Capabilities: Bridging In/Out connector facilitates connection between multiple Power Vector amps and mixers.
• Volume Control: Independent volume control for each of the eight module bays for customized audio settings.
• LED Indicators: Two-color LED for each channel indicates input signal status or clipping to prevent overload.
• Equalization Control: Bass and treble control with a bypass switch located in module bay 6 for tailored sound.
• External Equipment Integration: Signal-processing insert jacks allow inline connection of external equipment between pre-amp output and power amp input.
• Buffered Output Signal: Pre-EQ unbalanced buffered output signal enables smooth integration with other audio equipment.
• Convenience Receptacle: Grounded, unswitched AC convenience receptacle with 500W maximum capacity provided for powering external devices.
• Security Features: 8 module security cover/filler plates included with amplifier (PVMC) for protection.
• Rack Space: Compact design, only 2 rack spaces high (3-1/2"), fits standard audio racks.
• Safety Compliance: Listed to UL Standard 60065 for safe use in the U.S. and Canada.
