Bogen TERRA-4IO 4 Control Contacts Input and 4 Relay Output Interface

The TERRA-4IO from Bogen is an advanced IP, POE control interface unit that features 4 control contacts input and 4 relay output, along with an RS232 serial port. This versatile unit is perfect for applications that need a straightforward solution to activate and monitor analogue contact closures. It supports 3rd party control via the serial port and is easily configurable through a user-friendly web interface that allows for priority and event management as well as logic control.

Features

• Contact Inputs: 4 control contacts input for seamless integration with various devices and systems.
• Contact Outputs: 4 relay outputs enabling reliable activation of connected devices.
• SNMP Support: Simple Network Management Protocol for efficient device management on IP networks, enhancing monitoring capabilities.
• Web Browser Interface: User-friendly web interface for straightforward management and monitoring of all features and functionalities.
• RS232 Connectivity: Allows for 3rd party control and activation of I/O contacts, adding versatility for different control systems.
• Internal Storage: 80 MB of internal storage for recording data and message storage, enhancing its functionality.
• Power Options: Compatible with PoE (Power over Ethernet) or 24 VDC power supply for flexible deployment.
• LED Indicators: Power and Status LED indicators for at-a-glance operational status.

Bogen TERRA-4IO Detailed Specifications
