Hanwha Vision TCIS-3 Outdoor Audio Intercom

The Hanwha Vision TCIS-3 Outdoor Audio Intercom is designed to provide a robust audio-only communication solution for various environments. Key features include Full Duplex audio technology, Active Noise Control, and a durable IP66-rated enclosure, ensuring reliability in outdoor settings. Its high-performance specifications allow for clear audio transmission, making it ideal for building security and public areas.

Hanwha Vision TCIS-3 Intercom Features

• Open Duplex at 95dB, thanks to an anechoic speaker design and rigid aluminum frame, enhances clarity in conversations.
• Active Noise Reduction (up to 30dB) and Automatic Volume Control ensure effective communication in noisy environments.
• Digital MEMS microphones capture a wider spectrum of the human voice, resulting in superior audio quality.
• Class-D 10W amplifier paired with a 10W speaker allows broadcasting at up to 105dB for clear announcements.
• Supports a wide array of IP protocols (SIP, SNMP, HTTP, TFTP, Syslog) for versatile integration options.
• Easy configuration via standard web browsers or bulk setup with dedicated software for efficiency.
• Control relay and I/Os over IP for enhanced functionality.
• Powered via PoE or local 24-48 VDC, providing flexible installation options.
• Upload custom audio messages to enhance user interaction.
• Designed to meet Disability Act requirements for accessibility.
• Audio Presence ensures crystal clear communication.
• Automatic volume adjustment for optimal sound pressure levels as needed.
• Background noise cancellation improves audio clarity.
• Dirt, dust, and water-resistant with an IP-66 rating ensures durability in harsh conditions.
• Constructed with a robust die-cast aluminum frame rated IK08 for impact resistance.
• Supports a broad set of IP and networking standards for compatibility.
• Black thermoplastic front plate with a single button for simplicity.
• Ideal for building security and public environments to ensure safety.
• SIP, UL, Cisco Certified, Avaya Certified, NEC Certified for reliability.
• Operating temperature range of -40 °C to 70 °C (-40 °F to 158 °F) with UV resistance for outdoor use.
• Note: Optional mount (TA-1/TA-18/TA-5) is required for installation.
