Bogen M450 M-Class Dual-Channel Amplifier, 450 Watts

The M450 from Bogen is a M-Class amplifier that delivers on what professional sound installers need most – Flexibility, Power, and Reliability. It features 3 modes of operation, a robust dual-channel design, and exceptional performance characteristics that make it suitable for a variety of applications.

Bogen M450 M-Class Amplifier Features

• Power Output: 900W for 70V speaker systems, ensuring ample power for large venues.
• Stereo Performance: 450W per channel @ 4 ohms, providing high-quality audio for stereo setups.
• Operational Flexibility: Three modes of operation (Stereo, Dual Mono, 70V Mono) for versatile applications.
• Sound Quality: Low noise, low distortion, and high slew rate for pristine audio delivery.
• Input Versatility: Flexible modular input capability (2 module capacity) to accommodate various input types.
• Professional Input Module: Includes high-impedance input module with gain selection for superior adaptability.
• Customizable Frequency Response: Three selectable low-frequency roll-off choices to tailor sound output.
• Mixer Functionality: 2x1 mixer function when in mono modes for added control over audio sources.
• Insert Connections: Designed for outboard equipment integration in mono modes.
• Output Feeds: Post- and Pre-EQ Output Feeds with summed mono out in stereo mode.
• Robust Protection Features: DC, overload, short circuit, and thermal protection circuits for enhanced reliability.
• Speaker Safety: Clip limiting circuits that protect speakers from overload.
• Power Efficiency: Power-saving Sleep Mode for energy conservation during intermittent use.
• Operational Indicators: Status, Signal, and Clip/Limit indicators for real-time monitoring.
• Voltage Stabilization: Back-Slope AC voltage stabilization to maintain performance across varying AC line voltages.
• Durability: Heavy-gauge steel chassis with cast aluminum front panel for longevity.
• Accessible Controls: Recessed volume control knobs with snap-on protective cover to prevent accidental adjustments.
• Rack Compatibility: Mounts in 2 rack spaces (3-1/2") and is directly stackable without additional space required.
• Cooling System: Two independent, continuously variable, cooling fans ensure dependable and quiet operation.
• Maintenance-Friendly: Easily removable front fan grilles with filters for straightforward cleaning.
• Impedance Stability: Stable into 2-ohm loads for flexibility with various speaker configurations.
• Certification: Listed to UL Standard 60065 for safety compliance in the US and Canada.

Bogen M450 Detailed Specifications
