Louroe Electronics LE-328 Audio Interface Adapter

The LE-328 Audio Interface Adapter serves as an interconnection device between a Louroe line level microphone and a DVR/VCR, computer sound card, or IP network cameras with audio and video servers with audio. Input side contains a terminal block to receive wiring from the microphone and a jack for 12Vdc power input. The output side contains two types of connections to accommodate almost all recording device audio inputs:
- An RCA output for connection to a DVR/VCR with an RCA input
- A 3.5mm (minijack) stereo output for connection to a computer soundcard or DVR with a 3.5mm stereo audio input

Features

• Interfaces Louroe Verifact Microphone to audio recording device
• Provides power to the microphone
• RCA and 3.5mm outputs, wires included
• Variable volume control
• 12 Vdc power supply included
• Compatible with all Louroe Verifact Microphones
